Danfoss FIA 25 straightway strainer housing, 25 mm (1 in) butt weld EN 10220, 52 bar, steel
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss FIA 25 in-line strainer housing for the SVL Flexline industrial-refrigeration range. Traps scale and debris to protect downstream valves, pumps and controls. Straightway body with butt weld connections to EN 10220; 25 mm (1 in) nominal size. Maximum working pressure 52 bar (754 psig); media temperature range -60 to 150 C (-76 to 302 F). Steel body suits HCFC, non-flammable HFC, R717 (ammonia) and R744 (CO2) systems. Supplied with cover; the filter insert (mesh grade, plain or pleated) is ordered separately.
Technical Specifications
- Type
- Strainer housing, FIA 25
- Code number
- 148B5443
- Series
- SVL Flexline (FIA strainer)
- Product group
- Strainers
- Nominal size
- 25 mm (1 in)
- Direction
- Straightway
- Connection
- Butt weld
- Connection standard
- EN 10220
- Equipment
- Cover
- Body material
- Steel
- Maximum working pressure
- 52 bar (754 psig)
- Media temperature range
- -60 to 150 C (-76 to 302 F)
- Kv value
- 10.5-14.5 m3/h depending on filter insert grade (µ100 plain 10.5, µ100 pleated 13.8)
- Applicable media
- HCFC, HFC, R717 (ammonia), R744 (CO2)
- Conformity assessment
- PED Article 4, paragraph 3 (sound engineering practice)
- Approvals
- CE
- Net weight
- 2.88 kg
- EAN
- 5702428476621
- China RoHS compliance
- Yes
- Colour Paint
- Reddish brown
- Connection Code
- (2001:D26:25)
- Connection material
- Steel
- Cv value [gal/min] 100 plain
- 47.11 gal/min
- Cv value [gal/min] 100 pleated
- 60.76 gal/min
- Cv value [gal/min] 150 plain
- 46.23 gal/min
- Cv value [gal/min] 38 plain
- 51.07 gal/min
- Cv value [gal/min] 72 plain
- 48.87 gal/min
- Cv value [gal/min] 72 pleated
- 63.84 gal/min
- EU RoHS compliance
- Yes
- Flow direction indicator
- Embossed 1-way arrow
- Fluid Group
- 1
- Inlet connection size [in]
- 1 in
- Inlet connection size [mm]
- 25 mm
- Inlet connection type
- Butt weld
- Kv value [m3/h] µ100 plain
- 10.5 m³/h
- Kv value [m3/h] µ150 plain
- 10.7 m³/h
- Kv value [m3/h] µ150 pleated
- 13.8 m³/h
- Kv value [m3/h] µ250 plain
- 11.1 m³/h
- Kv value [m3/h] µ250 pleated
- 14.5 m³/h
- Kv value [m3/h] µ500 plain
- 11.6 m³/h
- Max. Working Pressure [bar]
- 52 bar
- Max. Working Pressure [psig]
- 754 psig
- Outlet connection size [in]
- 1 in
- Outlet connection size [mm]
- 25 mm
- Outlet connection type
- Butt weld
- PED category
- Art. 4, par. 3
- REACH Candidate List substances
- No
- Refrigerants
- R113
- Temperature range [°C] [max]
- 150 °C
- Temperature range [°C] [min]
- -60 °C
- Temperature range [°F] [max]
- 302 °F
- Temperature range [°F] [min]
- -76 °F
- Valve version
- Standard version
Standards & Compliance
- Size / Series
- 25 mm
- Material
- Steel
- Pressure Rating
- 52 bar
- Temperature Range
- -60 to 150 C
- HS Code
- 8421.39
Compatibility & Fitment
Danfoss FIA in-line strainer housing for the SVL Flexline industrial-refrigeration range. Protects downstream valves, pumps and controls by trapping scale and debris. Select by nominal size, body direction (angleway / straightway) and connection (weld standard). The filter insert (mesh grade, plain or pleated) is ordered separately; butt weld, socket weld and different weld standards are separate housing codes and are not interchangeable.
