Danfoss REG-SB SS 20 straightway hand regulating valve, stainless, butt weld EN 10220, cap, 3/4 in (20 mm), 52 bar
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss REG-SB SS 20 straightway hand-operated regulating (throttling) valve for industrial-refrigeration line service, code 148B5390. REG-SB carries the B-cone for the higher of the two REG flow characteristics; the SS designation is the stainless-steel body for improved corrosion resistance on CO2 (R744) and ammonia (R717) duty. This straightway body carries butt-weld inlet and outlet to EN 10220, size 3/4 in (20 mm) — distinct from the ASME Sch40 straightway (148B6488) and the long-neck REG-SB SS HL 20 (148B5951). Stainless steel body and connections; regulating cone with embossed one-way flow arrow; maximum working pressure 52 bar (754 psig); media temperature range -60 to 150 C (-76 to 302 F); Kv 5 m3/h (Cv 5.8 gal/min). Cap operated. Suits HCFC, non-flammable HFC, R717 and R744 systems.
Technical Specifications
- Type
- REG-SB SS 20 (hand-operated regulating valve)
- Code number
- 148B5390
- Series
- REG-SA SS / REG-SB SS (Flexline stainless hand regulating valves)
- Function
- Hand regulating (throttling) valve
- Cone
- B-cone (REG-SB)
- Nominal size
- DN20 — 3/4 in (20 mm)
- Direction
- Straightway
- Equipment
- Cap
- Flow direction
- Embossed one-way arrow
- Inlet connection type
- Butt weld
- Outlet connection type
- Butt weld
- Connection standard
- EN 10220
- Connection size
- 3/4 in (20 mm)
- Body material
- Stainless steel
- Connection material
- Stainless steel
- Maximum working pressure
- 52 bar (754 psig)
- Media temperature range
- -60 to 150 C (-76 to 302 F)
- Kv value
- 5 m3/h
- Cv value
- 5.8 gal/min
- Applicable media
- HCFC, HFC, R717 (ammonia), R744 (CO2)
- CE mark
- Yes
- PED category
- Art. 4, par. 3
- Approvals
- CE, EAC (LLC CDC TYSK)
- Net weight
- 1.8 kg
- EAN
- 5702428842266
Standards & Compliance
- Size / Series
- 3/4 in (20 mm)
- Material
- Stainless steel
- Pressure Rating
- 52 bar
- Temperature Range
- -60 to 150 C
- HS Code
- 8481.80
Compatibility & Fitment
Danfoss REG-SB SS Flexline stainless hand regulating valve, straightway EN 10220 butt-weld variant. Select by cone (SA = lower Kv A-cone, SB = higher Kv B-cone), nominal size (DN20 / 3/4 in) and connection standard. The EN 10220 and ASME Sch40 bodies are separate codes; the HL suffix is the long-neck version — confirm cone, neck and pipe connection before ordering.
