Danfoss SVA-S 15 straightway shut-off valve, socket weld inlet / NPT outlet, cap, 1/2 in (15 mm), 52 bar (code 148B5267)
Danfoss · HVAC & Refrigeration · Globe Valves
Danfoss SVA-S 15 straightway shut-off (stop) valve for industrial-refrigeration line service, code 148B5267. Standard-neck (SVA-S) carbon-steel Flexline stop valve, size 1/2 in (15 mm), with a socket-weld inlet to ANSI B16.11 and an NPT threaded outlet to ASME B1.20.1 - a mixed weld-to-thread transition distinct from the all-butt-weld and all-socket bodies. Bi-flow; maximum working pressure 52 bar (754 psig); media temperature range -60 to 150 C (-76 to 302 F); Kv 7 m3/h (Cv 8.12 gal/min). Cap operated. Straightway body places inlet and outlet in line.
Specifications
- Part number
- 148B5267
- HS code
- 8481.80
- Material
- Steel
- Pressure rating
- 52 bar
- Temperature range
- -60 to 150 C
- Standard size
- 1/2 in (15 mm)
Compatibility
Danfoss SVA-S Flexline standard-neck stop valve. Select by nominal size (DN15 / 1/2 in), body direction (straightway), connection format (socket-weld inlet / NPT outlet) and operator (cap). SVA-S is standard-neck; SVA-L is long-neck - confirm neck length and pipe connection before ordering.
Approvals
