Danfoss FIA 20 straightway strainer housing, socket weld ASME B16.11, 3/4 in (20 mm), 52 bar

Danfoss FIA 20 straightway strainer (filter) housing for industrial-refrigeration line service, code 148B5348. Flexline strainer housing, size 3/4 in (20 mm), with socket-weld inlet and outlet to ASME B16.11 in a straightway (in-line) body with bolted cover - distinct from the butt-weld ASME Schedule 80 straightway FIA 20 housing. Maximum working pressure 52 bar (754 psig); media temperature range -60 to 150 C (-76 to 302 F). Embossed 1-way flow arrow. Removable filter insert (ordered separately) retains particulates upstream of valves and controls.

Type

FIA 20 (strainer / filter housing)

Code number

148B5348

Series

FIA (Flexline strainers)

Function

Strainer (filter) housing

Nominal size

3/4 in (20 mm)

Direction

Straightway

Equipment

Cover

Flow direction

Embossed 1-way arrow

Inlet connection type

Socket weld

Outlet connection type

Socket weld

Connection standard

ASME B16.11

Connection size

3/4 in (20 mm)

Body material

Steel

Connection material

Steel

Maximum working pressure

52 bar (754 psig)

Media temperature range

-60 to 150 C (-76 to 302 F)

Applicable media

HCFC, HFC, R717 (ammonia), R744 (CO2)

CE mark

Yes

PED category

Art. 4, par. 3

Approvals

CE

Net weight

1.522 kg

EAN

5702428476423

Size / Series

3/4 in (20 mm)

Material

Steel

Pressure Rating

52 bar

Temperature Range

-60 to 150 C

HS Code

8421.39
