Danfoss SVA-L 20 straightway long-neck shut-off valve, NPT ANSI/ASME B1.20.1, handwheel, 3/4 in (20 mm), 52 bar

Danfoss SVA-L 20 straightway long-neck shut-off (stop) valve for industrial-refrigeration line service, code 148B5374. Long-neck (SVA-L) carbon-steel Flexline stop valve, size 3/4 in (20 mm), with NPT threaded inlet and outlet to ANSI/ASME B1.20.1 in a straightway (in-line) body, handwheel operated - the NPT-threaded counterpart of the butt-weld and socket-weld SVA-L 20 straightway bodies. The long neck suits insulated lines. Bi-flow; maximum working pressure 52 bar (754 psig); media temperature range -60 to 150 C (-76 to 302 F); Kv 7 m3/h (Cv 8.12 gal/min).

Type

SVA-L 20 (long-neck stop / shut-off valve)

Code number

148B5374

Series

SVA-S / SVA-L (Flexline stop and shut-off valves)

Function

Manual shut-off (stop) valve

Nominal size

3/4 in (20 mm)

Direction

Straightway

Equipment

Handwheel

Neck

Long (SVA-L)

Flow direction

Bi-flow

Inlet connection type

NPT

Outlet connection type

NPT

Connection standard

ANSI/ASME B1.20.1

Connection size

3/4 in (20 mm)

Body material

Steel

Connection material

Steel

Maximum working pressure

52 bar (754 psig)

Media temperature range

-60 to 150 C (-76 to 302 F)

Kv value

7 m3/h

Cv value

8.12 gal/min

Applicable media

HCFC, HFC, R717 (ammonia), R744 (CO2)

CE mark

Yes

PED category

Art. 4, par. 3

Approvals

CE, EAC

Net weight

1.632 kg

EAN

5702428469081

Size / Series

3/4 in (20 mm)

Material

Steel

Pressure Rating

52 bar

Temperature Range

-60 to 150 C

HS Code

8481.80
