Danfoss SVA-L 15 angleway shut-off valve, NPT threaded, cap, 1/2 in (15 mm), 52 bar (code 148B5265)
Danfoss · HVAC & Refrigeration · Globe Valves
Danfoss SVA-L 15 angleway shut-off (stop) valve for industrial-refrigeration line service, code 148B5265. This variant carries NPT (National Pipe Thread) inlet and outlet to ANSI/ASME B1.20.1, size 1/2 in (15 mm) — distinct from the butt-weld and socket-weld SVA-L 15 bodies. SVA-L is the long-neck (extended bonnet) version of the Flexline stop valve, suited to thicker insulation. Steel body and connections; bi-flow; maximum working pressure 52 bar (754 psig); media temperature range -60 to 150 C (-76 to 302 F); Kv 8.5 m3/h (Cv 9.86 gal/min). Operated with a cap. Suits HCFC, non-flammable HFC, R717 (ammonia) and R744 (CO2) systems. Angleway body places inlet and outlet at 90 degrees.
Specifications
- Part number
- 148B5265
- HS code
- 8481.80
- Material
- Steel
- Pressure rating
- 52 bar
- Temperature range
- -60 to 150 C
- Standard size
- 1/2 in (15 mm)
Compatibility
Danfoss SVA-L Flexline shut-off valve, NPT-threaded connection variant. Select by nominal size (DN15 / 1/2 in), body direction (angleway) and operator (cap). NPT, butt-weld and socket-weld bodies are separate codes and are not interchangeable — confirm the mating pipe connection before ordering. SVA-S is the standard-neck version; SVA-L is the long-neck version.
Approvals
