Danfoss FIA 20 straightway strainer housing, 20 mm (3/4 in) butt weld ASME B36.10M Schedule 80, 52 bar, steel

Danfoss FIA 20 in-line strainer housing for the SVL Flexline industrial-refrigeration range. Traps scale and debris to protect downstream valves, pumps and controls. Straightway body with butt weld connections to ASME B36.10M Schedule 80; 20 mm (3/4 in) nominal size. Maximum working pressure 52 bar (754 psig); media temperature range -60 to 150 C (-76 to 302 F). Steel body suits HCFC, non-flammable HFC, R717 (ammonia) and R744 (CO2) systems. Supplied with cover; the filter insert (mesh grade, plain or pleated) is ordered separately.

Type

Strainer housing, FIA 20

Code number

148B5347

Series

SVL Flexline (FIA strainer)

Product group

Strainers

Nominal size

20 mm (3/4 in)

Direction

Straightway

Connection

Butt weld

Connection standard

ASME B36.10M Schedule 80

Equipment

Cover

Body material

Steel

Maximum working pressure

52 bar (754 psig)

Media temperature range

-60 to 150 C (-76 to 302 F)

Kv value (µ100 plain)

5.3 m3/h

Kv value (µ150 plain)

5.4 m3/h

Kv value (µ150 pleated)

6.9 m3/h

Kv value (µ250 plain)

5.6 m3/h

Kv value (µ500 plain)

5.9 m3/h

Applicable media

HCFC, HFC, R717 (ammonia), R744 (CO2)

Conformity assessment

PED Article 4, paragraph 3 (sound engineering practice)

Approvals

CE

Net weight

1.33 kg

EAN

5702428476317

Size / Series

20 mm

Material

Steel

Pressure Rating

52 bar

Temperature Range

-60 to 150 C

HS Code

8421.39
