Danfoss MBT 5252 temperature sensor with built-in 4-20 mA transmitter, Pt 100, 50 mm insertion, G 1/2 process connection (code 084Z6022)
Danfoss · Sensors & Instrumentation · Temperature Sensors
Danfoss MBT 5252 heavy-duty insertion temperature sensor with integral 4-20 mA transmitter, code 084Z6022 (type designation MBT 5252-0011-0050-0200-G112). Combines a Pt 100 platinum measuring insert (Class B per EN 60751) with a two-wire transmitter that outputs a 4-20 mA signal proportional to the calibrated measuring range 0 to +120 C (+32 to +248 F); supply 8-35 V DC. Insertion length 50 mm; G 1/2 male (ISO 228-1-A) process connection; AISI 316 Ti stainless-steel protection tube, 10 mm diameter. Sensor operating range -50 to +200 C (-58 to +392 F). Type B connection head, Pg 16; IP65 enclosure per IEC 60529. CE marked. For cooling water, oil and refrigeration circuits in industry and marine plant.
Specifications
- Part number
- 084Z6022
- HS code
- 9025.19
- Material
- AISI 316 Ti stainless steel
- Temperature range
- -50 to +200 C (-58 to +392 F)
- IP rating
- IP65
- Standard size
- 50 mm insertion
- Thread standard
- ISO 228-1-A
Compatibility
MBT 5252 insertion sensor with integral 4-20 mA transmitter (calibrated 0 to +120 C (+32 to +248 F)). Confirm the 4-20 mA input, 8-35 V DC supply, insertion length (50 mm) and thread (G 1/2) suit the controller and pocket.
Standards
- EN 60751
- IEC 60529
- ISO 228-1
Approvals
