Danfoss CVP-M constant-pressure pilot valve, medium pressure 4 to 28 bar, for ICS servo-operated main valves

Danfoss CVP-M constant-pressure pilot valve for the ICV Flexline / ICS servo-operated main-valve range, code 027B0921. Fitted in the pilot channel of an ICS main valve, the CVP holds a constant pressure at the main-valve inlet, independent of the downstream pressure. This SKU is the medium-pressure version with a regulating range of 4 to 28 bar (58 to 406 psig). Flow coefficient Kv 0.4 m3/h (Cv 0.46). Maximum working pressure 65 bar (943 psig); media temperature range -60 to 120 C (-76 to 248 F). Zn (TLP) surface coating; supplied as a 6-piece multipack with gasket. For HCFC, HFC, R717 (ammonia) and R744 (CO2) systems.

Type

CVP-M (constant-pressure pilot valve)

Code number

027B0921

Series

CVP / CVPP / CVC / CVE / EVM / CVH pilot valves (ICV Flexline)

Function

Constant-pressure pilot — holds constant inlet pressure

Valve version

Medium pressure

Regulating range

4 to 28 bar (58 to 406 psig)

Kv value

0.4 m3/h

Cv value

0.46 gal/min

Maximum working pressure

65 bar (943 psig)

Media temperature range

-60 to 120 C (-76 to 248 F)

Surface coating

Zn (TLP)

Net weight

1.389 kg

Gross weight

1.632 kg

Packing format

Multi pack (6 pc)

Parts included

Gasket

Fluid group

1

PED category

Art. 4, par. 3

Brand

ICV Flexline

Approvals

EAC, UL

EAN

5702428557634

Material

Steel

Pressure Rating

65 bar

Temperature Range

-60 to 120 C

HS Code

8481.80
