Danfoss CVC-M pressure-operated pilot valve, medium pressure 4 to 28 bar, for ICS servo-operated main valves

Danfoss CVC-M pressure-operated pilot valve for the ICV Flexline / ICS servo-operated main-valve range, code 027B0941. The CVC opens or closes the pilot channel in response to a pressure sensed at an external reference connection, giving the ICS main valve a constant-pressure control function referenced to a remote point in the system. This SKU is the medium-pressure version with a regulating range of 4 to 28 bar (58 to 406 psig). Flow coefficient Kv 0.2 m3/h (Cv 0.23). Maximum working pressure 65 bar (943 psig); media temperature range -60 to 120 C (-76 to 248 F). Zn (TLP) surface coating; supplied as a 6-piece multipack with adapter and gasket. For HCFC, HFC, R717 (ammonia) and R744 (CO2) systems.

Type

CVC-M (pressure-operated pilot valve)

Code number

027B0941

Series

CVP / CVPP / CVC / CVE / EVM / CVH pilot valves (ICV Flexline)

Function

Pressure-operated pilot with external reference connection

Valve version

Medium pressure

Regulating range

4 to 28 bar (58 to 406 psig)

Kv value

0.2 m3/h

Cv value

0.23 gal/min

Maximum working pressure

65 bar (943 psig)

Media temperature range

-60 to 120 C (-76 to 248 F)

Surface coating

Zn (TLP)

Net weight

1.78 kg

Gross weight

2.072 kg

Packing format

Multi pack (6 pc)

Parts included

Adapter, Gasket

Fluid group

1

PED category

Art. 4, par. 3

Brand

ICV Flexline

Approvals

EAC, UL

EAN

5702428557689

Material

Steel

Pressure Rating

65 bar

Temperature Range

-60 to 120 C

HS Code

8481.80
