Danfoss CVCE-L constant-pressure pilot valve, low pressure -0.66 to 7 bar, hydrocarbon refrigerants, for ICS servo-operated main valves

Danfoss CVCE-L constant-pressure pilot valve for the ICV Flexline / ICS servo-operated main-valve range, code 027B1040. This is the constant-pressure pilot released for hydrocarbon refrigerants (R290 propane, R600 butane, R600a isobutane, R170 ethane, R1270 propylene). Fitted in the pilot channel of an ICS main valve, it holds a constant pressure at the main-valve inlet. This SKU is the low-pressure version with a regulating range of -0.66 to 7 bar (-9.5 to 102 psig). Flow coefficient Kv 0.2 m3/h (Cv 0.46). Maximum working pressure 52 bar (754 psig); media temperature range -40 to 120 C (-40 to 248 F). Zn (TLP) surface coating; supplied as a 6-piece multipack with gasket.

Type

CVCE-L (constant-pressure pilot valve, hydrocarbon)

Code number

027B1040

Series

CVP / CVPP / CVC / CVE / EVM / CVH pilot valves (ICV Flexline)

Function

Constant-pressure pilot — holds constant inlet pressure

Valve version

Low pressure

Regulating range

-0.66 to 7 bar (-9.5 to 102 psig)

Kv value

0.2 m3/h

Cv value

0.46 gal/min

Maximum working pressure

52 bar (754 psig)

Media temperature range

-40 to 120 C (-40 to 248 F)

Surface coating

Zn (TLP)

Net weight

1.454 kg

Gross weight

2.035 kg

Packing format

Multi pack (6 pc)

Parts included

Gasket

Applicable media

R1270, R170, R290, R600, R600a (hydrocarbon refrigerants)

Fluid group

1

PED category

Art. 4, par. 3

Brand

ICV Flexline

Approvals

EAC

EAN

5715162462454

Material

Steel

Pressure Rating

52 bar

Temperature Range

-40 to 120 C

HS Code

8481.80
