Danfoss CVPP-M differential-pressure pilot valve, medium pressure 4 to 28 bar, for ICS servo-operated main valves (code 027B0931)
Danfoss · HVAC & Refrigeration · Pilot Valves
Danfoss CVPP-M differential-pressure pilot valve for the ICV Flexline / ICS servo-operated main-valve range, code 027B0931. Fitted in the pilot channel of an ICS main valve, the CVPP holds a constant differential pressure across the main valve, referenced to an external pressure connection. This SKU is the medium-pressure version with a regulating range of 4 to 28 bar (58 to 406 psig). Flow coefficient Kv 0.4 m3/h (Cv 0.46). Maximum working pressure 65 bar (943 psig); media temperature range -60 to 120 C (-76 to 248 F). Zn (TLP) surface coating; supplied as a 6-piece multipack with adapter and gasket. For HCFC, HFC, R717 (ammonia) and R744 (CO2) systems.
Specifications
- Part number
- 027B0931
- HS code
- 8481.80
- Material
- Steel
- Pressure rating
- 65 bar
- Temperature range
- -60 to 120 C
Compatibility
Mounts in the pilot channel of Danfoss ICS servo-operated main valves for constant-differential-pressure control. Range sibling: CVPP-L low -0.66 to 7 bar (027B0930). Requires the external reference connection (adapter supplied). Confirm the ICS valve size before ordering.
Approvals
