Danfoss MBT 9110 temperature transmitter, Pt 100 input, 4-20 mA output, -50 to +100 C range

Danfoss MBT 9110 head-mount temperature transmitter, code 084Z3108 (type designation MBT 9110-000B-G410). Two-wire loop-powered transmitter that converts a Pt 100 resistance input into a 4-20 mA output linearly scaled across the -50 to +100 C (150 C span) measuring range, for refrigeration, HVAC and machinery temperature signalling. Pt 100 platinum input, Class B per EN 60751. 8-35 V DC supply; Compact head-mount module; screw terminals, 2-wire. IP00 enclosure per IEC 60529; maximum ambient 85 C. CE marked. Mounts in a sensor connection head or on a DIN carrier; pair with an MBT 5252/3250 measuring insert.

Type

MBT 9110 (head-mount temperature transmitter)

Type designation

MBT 9110-000B-G410

Code number

084Z3108

Sensor element

Pt 100 platinum resistance input (100 ohm at 0 C)

Tolerance

Class B per EN 60751

Measuring range

-50 to +100 C

Output signal

4-20 mA (2-wire, loop-powered)

Supply voltage

8-35 V DC

Electrical connection

Screw terminals, 2-wire (Compact head-mount module)

Enclosure rating

IP00 per IEC 60529

Max ambient temperature

85 C (185 F)

Packing quantity

12 pc

Net weight

0.041 kg

Approvals

CE

EAN

5702423241637

Product group

Sensors

Ambient temperature max. [°C]

85 °C

Ambient temperature max. [°F]

185 °F

Approval

CE

CE mark

Yes

China RoHS compliance

Out of scope

EEE category

5 small equipment (any external dimension < 50 cm)

Electrical connection size

2 terminals

Enclosure rating IP

IP00

EU RoHS compliance

Yes with exemptions

EU RoHS exemption clause

6(c)

In scope of WEEE

Yes

Insertion type

Fixed

Measuring range [°C] [max]

100 °C

Measuring range [°C] [min]

-50 °C

Measuring range [°F] [max]

212 °F

Measuring range [°F] [min]

-58 °F

Output signal [mA] [max]

20 mA

Output signal [mA] [min]

4 mA

REACH Candidate List substances

Lead (CAS no. 7439-92-1)

Sensor elem. resistance [Ohm]

100 Ohm

Sensor element [pc]

1 pc

Sensor element type

Pt

Supply voltage [V] DC [max]

35 V

Supply voltage [V] DC [min]

8 V

Temperature range [°C] [max]

850 °C

Temperature range [°C] [min]

-200 °C

Temperature range [°F] [max]

1562 °F

Temperature range [°F] [min]

-328 °F

Transmitter setting range [°C] [max]

100 °C

Transmitter setting range [°C] [min]

-50 °C

Transmitter setting range [°F] [max]

212 °F

Transmitter setting range [°F] [min]

-58 °F

Transmitter type

Standard

Material

Glass-filled polyamide housing

Temperature Range

-50 to +100 C

IP Rating

IP00

HS Code

9025.19
