Danfoss MBT 9110 temperature transmitter, Pt 100 input, 4-20 mA output, 0 to +160 C range
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss MBT 9110 head-mount temperature transmitter, code 084Z3155 (type designation MBT 9110-000B-J116). Two-wire loop-powered transmitter that converts a Pt 100 resistance input into a 4-20 mA output linearly scaled across the 0 to +160 C (160 C span) measuring range, for refrigeration, HVAC and machinery temperature signalling. Pt 100 platinum input, Class B per EN 60751. 8-30 V DC supply; Standard EEx, high lid; screw terminals, 2-wire. IP54 enclosure per IEC 60529; maximum ambient 85 C. CE marked. Mounts in a sensor connection head or on a DIN carrier; pair with an MBT 5252/3250 measuring insert.
Technical Specifications
- Type
- MBT 9110 (head-mount temperature transmitter)
- Type designation
- MBT 9110-000B-J116
- Code number
- 084Z3155
- Sensor element
- Pt 100 platinum resistance input (100 ohm at 0 C)
- Tolerance
- Class B per EN 60751
- Measuring range
- 0 to +160 C
- Output signal
- 4-20 mA (2-wire, loop-powered)
- Supply voltage
- 8-30 V DC
- Electrical connection
- Screw terminals, 2-wire (Standard EEx, high lid)
- Enclosure rating
- IP54 per IEC 60529
- Max ambient temperature
- 85 C (185 F)
- Packing quantity
- 12 pc
- Net weight
- 0.115 kg
- Approvals
- CE
- EAN
- 5702423261345
- Product group
- Sensors
- Ambient temperature max. [°C]
- 85 °C
- Ambient temperature max. [°F]
- 185 °F
- Approval
- CE
- CE mark
- Yes
- China RoHS compliance
- Out of scope
- EEE category
- 5 small equipment (any external dimension < 50 cm)
- Electrical connection size
- 2 terminals
- Enclosure rating IP
- IP54
- EU RoHS compliance
- Yes with exemptions
- EU RoHS exemption clause
- 6(c)
- In scope of WEEE
- Yes
- Insertion type
- Fixed
- Measuring range [°C] [max]
- 160 °C
- Measuring range [°C] [min]
- 0 °C
- Measuring range [°F] [max]
- 320 °F
- Measuring range [°F] [min]
- 32 °F
- Output signal [mA] [max]
- 20 mA
- Output signal [mA] [min]
- 4 mA
- REACH Candidate List substances
- Lead (CAS no. 7439-92-1)
- Sensor elem. resistance [Ohm]
- 100 Ohm
- Sensor element [pc]
- 1 pc
- Sensor element type
- Pt
- Supply voltage [V] DC [max]
- 30 V
- Supply voltage [V] DC [min]
- 8 V
- Temperature range [°C] [max]
- 850 °C
- Temperature range [°C] [min]
- -200 °C
- Temperature range [°F] [max]
- 1562 °F
- Temperature range [°F] [min]
- -328 °F
- Transmitter setting range [°C] [max]
- 160 °C
- Transmitter setting range [°C] [min]
- 0 °C
- Transmitter setting range [°F] [max]
- 320 °F
- Transmitter setting range [°F] [min]
- 32 °F
- Transmitter type
- Standard EEx, high lid
Standards & Compliance
- Material
- Glass-filled polyamide housing
- Temperature Range
- 0 to +160 C
- IP Rating
- IP54
- HS Code
- 9025.19
Compatibility & Fitment
MBT 9110 head-mount transmitter. Confirm the 0 to +160 C measuring range matches the receiving controller/PLC scaling and that a 8-30 V DC loop supply is available. Accepts a Pt 100 sensor insert (e.g. MBT 5252 / MBT 3250) in the connection head.
