Danfoss MBT 120 sensor pocket (thermowell), 80 mm insertion, NPT 1/2-14 connection, AISI 316 Ti
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss MBT 120 sensor pocket (thermowell), code 084Z3124 (type designation MBT 120-630-080-8). Weld-in / screw-in protection pocket that lets an MBT 3560 or MBT 5560 transmitter insert be removed for service without draining or depressurising the system. Insertion length 80 mm; NPT 1/2-14 male (ANSI/ASME B1.20.1) process connection; AISI 316 Ti stainless-steel construction, 11 mm bore. Rated -50 to +200 C (-58 to +392 F). Sensor insert exchangeable. CE compliant.
Technical Specifications
- Type
- MBT 120 (sensor pocket / thermowell)
- Type designation
- MBT 120-630-080-8
- Code number
- 084Z3124
- Insertion length
- 80 mm
- Process connection
- NPT 1/2-14 (ANSI/ASME B1.20.1)
- Protection tube
- AISI 316 Ti stainless steel, 11 mm diameter
- Measuring range
- -50 to +200 C (-58 to +392 F)
- Packing quantity
- 40 pc
- Net weight
- 0.099 kg
- Approvals
- CE
- EAN
- 5702423248605
- Product group
- Accessories, sensors
- Connection material
- AISI 316 Ti
- Connection standard
- ANSI/ASME B1.20
- Connection type
- NPT
- Temperature range
- -50 °C to 200 °C
- UL mark
- No
- CE mark
- Yes
- REACH candidate-list substances
- No
- EEE category
- 5 small equipment (any external dimension < 50 cm)
- In scope of WEEE
- Yes
- Insertion type
- Fixed
- Process connection Male/Female
- Male
- Process connection material
- AISI 316 Ti
- Process connection size
- 1/2-14
- Process connection standard
- ANSI/ASME B1.20.1
- Process connection type
- NPT
- Protection tube diameter
- 11.0 mm
- Protection tube material
- AISI 316 TI
- EU RoHS compliance
- Yes
Standards & Compliance
- Size / Series
- 80 mm insertion
- Material
- AISI 316 Ti stainless steel
- Thread Standard
- ANSI/ASME B1.20.1
- Temperature Range
- -50 to +200 C (-58 to +392 F)
- HS Code
- 9025.90
Compatibility & Fitment
MBT 120 sensor pocket. Match the pocket insertion length (80 mm) and NPT 1/2-14 process thread to the sensor and the mounting boss; suits MBT 3560 / MBT 5560 transmitters.
