Danfoss KP75 thermostat, 0 to 40 °C, automatic reset, SPDT, room sensor 25 x 78 mm
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss KP75 thermostat (code 060L121266). Sensor (regulating) range 0 to 40 °C with an integral room sensor (25 x 78 mm); no capillary. Adjustable/fixed differential 3 to 10 K (adjustable, range-dependent); automatic reset; SPDT (single-pole double-throw) snap-action contact. room sensor 25 x 78 mm. Enclosure IP30, ambient -40 to +65 °C (-40 to 150 °F). Sensor (regulating) range 0 to 40 °C (32 to 104 °F). For temperature monitoring and control of non-aggressive media.
Technical Specifications
- Type
- KP75 thermostat
- Code number
- 060L121266
- Sensor (regulating) range
- 0 to 40 °C (32 to 104 °F)
- Differential
- 3 to 10 K (adjustable, range-dependent)
- Reset
- Automatic
- Contact system
- SPDT (single-pole double-throw)
- Sensor
- room sensor 25 x 78 mm
- NEMA enclosure rating
- 1
- Enclosure
- IP30
- Ambient temperature
- -40 to +65 °C (-40 to 150 °F)
- Electrical connection
- rubber cable gland 6-14 mm
- Contact rating
- AC15 10 A 400 V; AC1 16 A 400 V; AC3 16 A 400 V; DC13 12 W 220 V; LR 112 A 400 V
- Approvals
- CE, EAC, CCC, UL, DNV, BV, GL, LR, RINA, RMRS, LVD
- Product group
- Switches and thermostats
- Max. sensor temperature
- 80 °C
- Temperature range
- 0 °C to 40 °C
- UL approval file name
- E31024; MH27572
- UL mark
- Yes
- CE mark
- Yes
- REACH candidate-list substances
- Lead (CAS no. 7439-92-1); Cadmium oxide (CAS no.1306-19-0)
- Net weight
- 0.364 kg
- EAN
- 5702423159659
- Amb. Temp. Note
- 80 °C/176 °F for max 120 min
- Charge type
- Adsorption
- Contact function
- SPDT
- Diff. @ Max. range setting
- 3.0 K, 3.0 °C
- Diff. @ Min. range setting
- 4.0 K to 10.0 K, 4.0 °C to 10.0 °C
- Differential type
- Adjustable
- Electrical connection size
- 6-14 mm
- Electrical spec. standard
- EN 60947-5
- EN 60947 electrical properties
- Insulation: 400V; Pollution degree: 3; Rated impulse voltage: 4 kV; Short circuit prot, fuse: 16A
- EN 60947 wiring properties
- Flex, ferrules: 0.5-1.5 mm2; Flex, no ferrules: 0.7-2.5 mm2; Solid/stranded: 0.75-2.5 mm2
- Enclosure rating IP
- IP30
- Enclosure rating Nema (~)
- 1
- Parts included
- Screws
- Reset function
- Auto
- Sensor size (Ø x L)
- 25 x 78 mm
- Sensor type
- Room sensor
- EU RoHS compliance
- Yes
Standards & Compliance
- Material
- Integral room sensor; steel housing
- Temperature Range
- -40 to +65 °C (-40 to 150 °F)
- IP Rating
- IP30
- HS Code
- 9032.10
Compatibility & Fitment
Room thermostat for ambient temperature control 0 to 40 °C. SPDT contact wired NO or NC. Integral room sensor (no capillary). Verify regulating range and differential against the set point before ordering.
