Danfoss KP34 pressure switch, 0.14 to 1.07 bar, manual (max) reset, SPDT, G1/2
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss KP34 low-pressure switch (code 060-216366). Regulating range 0.14 to 1.07 bar, fixed differential 0.21 bar, manual reset on max, SPDT snap-action contact. G1/2 (ISO 228-1) male connection, IP30 enclosure, ambient -40 to +65 °C. Max working pressure 4 bar, max test pressure 6 bar. Manual reset locks out on over-pressure for safety limiting.
Technical Specifications
- Type
- KP34 low-pressure switch
- Code number
- 060-216366
- Regulating range
- 0.14 to 1.07 bar
- Differential
- 0.21 bar (fixed)
- Max working pressure (PB)
- 4 bar
- Max test pressure (Pe)
- 6 bar
- Reset
- manual (max), lock-out on over-pressure
- Contact system
- SPDT (single-pole double-throw)
- Contact load
- 16 A resirigide, single phase (120 Vac: 16 FLA / 96 LRA / 3 A pilot duty)
- Connection
- G1/2 (ISO 228-1) male
- Enclosure
- IP30
- Ambient temperature
- -40 to +65 °C (80 °C max 120 min)
- Pressure element
- bellows
- Product group
- Switches and thermostats
- Max. test pressure
- 87.0 psig
- Max. test pressure Pe
- 6.0 bar
- Approval
- CCC; CE; EAC; LLC CDC EURO-TYSK; LVD; RINA; RMRS; RoHS China; c UL us UL353, CS C22.2; c UL us UL873, CS C22.2
- UL approval file name
- E31024; MH27572
- UL approved refrigerants
- R1234yf; R1234ze(E); R452B; R454A; R454C; R455A
- UL mark
- Yes
- CE mark
- Yes
- REACH candidate-list substances
- Lead (CAS no. 7439-92-1); Cadmium oxide (CAS no.1306-19-0)
- Net weight
- 0.476 kg
- EAN
- 5702423263769
- Amb. Temp. Note
- 80 °C/176 °F for max 120 min
- Contact function
- SPDT
- Contact rating
- 120Vac,16FLA,96LRA,3APilotDuty; 16 A resistive, single phase; 240 V AC, 8 FLA, 48 LRA; 240V dc,12W pilot duty(0.05 A); 8 A resistive, single phase
- EEE category
- 5 small equipment (any external dimension < 50 cm)
- Electrical connection
- Rubber cable gland
- Electrical connection size
- 6-14 mm
- EN 60947 electrical properties
- Insulation: 400V; Pollution degree: 3; Rated impulse voltage: 4 kV; Short circuit prot, fuse: 16A
- EN 60947 wiring properties
- Flex, ferrules: 0.5-1.5 mm2; Flex, no ferrules: 0.7-2.5 mm2; Solid/stranded: 0.75-2.5 mm2
- Enclosure rating IP
- IP30
- Enclosure rating Nema (~)
- 1
- In scope of WEEE
- Yes
- Pressure connection size
- 1/2
- Pressure connection standard
- ISO 228-1
- Pressure connection type
- G
- Pressure Male/Female
- Male
- Pressure sensing element
- Bellows
Standards & Compliance
- Material
- Steel/zinc-plated housing; bellows pressure element
- Thread Standard
- G1/2 (ISO 228-1) male
- Pressure Rating
- PB 4 bar; max test 6 bar
- Temperature Range
- -40 to +65 °C (80 °C max 120 min)
- IP Rating
- IP30
- HS Code
- 9026.20
Compatibility & Fitment
Low-pressure safety switch with manual reset lock-out on over-pressure. SPDT contact wired NO or NC. G1/2 (ISO 228-1) male connection. Verify range/differential against the set point before ordering.
