Danfoss MBS 3300 Pressure Transmitter 0 to 40 bar Form E 4-Pin

Danfoss MBS 3300 compact pressure transmitter for general industrial and marine use. Range 0 to 40 bar (0 to 580 psi), 4-20 mA 2-wire output, AISI 316L stainless steel wetted parts. G 1/4 male Form E (DIN 3852-E / ISO 1179-2 Form E) port; 4-pin angular connector (EN 175301-803-A). Spec key MBS 3300-2631-A0GB04-2. Sealed gauge reference, overload 240 bar. EAN 5702428927802.

Type

MBS 3300

Range

0 to 40 bar (0 to 580 psi)

Reference

sealed gauge

Output

4-20 mA (2-wire)

Supply

9-32 V DC

Accuracy

<= +/-0.5% FS typ., +/-1% FS max

Wetted parts

AISI 316L stainless steel

Pressure connection

G 1/4 male (DIN 3852-E, Form E)

Electrical connection

Angular connector 4-pin, EN 175301-803-A

Enclosure

IP65

Ambient temp

-40 to +100 C

Medium temp

-40 to +125 C

Overload pressure

240 bar

Response time

4 ms max

Approvals

ATEX Ex ec IIA T4 Gc; CE; UL

Spec key

MBS 3300-2631-A0GB04-2

EAN

5702428927802

Part number

060G6451

Net weight

0.124 Kilogram

Product group

Sensors

+ supply

Pin 1

- common

Pin 2

Accuracy, max. [±FS%]

1 %

Accuracy, typical [±FS%]

0.5 %

Adj. zero point and span

No

Ambient temperature range [°C] [max]

100 °C

Ambient temperature range [°C] [min]

-40 °C

Ambient temperature range [°F] [max]

212 °F

Ambient temperature range [°F] [min]

-40 °F

Approval

ATEX

Approval comments

ATEX Ex ec IIA T4 Gc

CE mark

Yes

China RoHS compliance

Out of scope

Compensated temp. range [°C] [max]

100 °C

Compensated temp. range [°C] [min]

0 °C

Compensated temp. range [°F] [max]

212 °F

Compensated temp. range [°F] [min]

32 °F

EEE category

5 small equipment (any external dimension < 50 cm)

Electrical conn. Male/Female

Male

Electrical connection size

4 pin

Electrical connection standard

EN 175301-803-A

Enclosure rating IP

IP65

EU RoHS compliance

Yes with exemptions

EU RoHS exemption clause

6(c)

Flush diaphragm

No

High Clipping Level

22.4

In scope of WEEE

No

International Article Number

5702428927802

Intrinsically safe

No

Low Clipping level

3.6

Medium temperature range [°C] [max]

125 °C

Medium temperature range [°C] [min]

-40 °C

Medium temperature range [°F] [max]

257 °F

Medium temperature range [°F] [min]

-40 °F

Non-linearity BFSL [±FS%]

0.5 %

Output signal

Current

Output signal [mA] [max]

20 mA

Output signal [mA] [min]

4 mA

Overload pressure max. [bar]

240 bar

Overload pressure max. [psi]

3480 psi

Pressure connection HEX [mm]

27 mm

Pressure connection size

1/4

Pressure connection standard

DIN 3852-E

Pressure connection type

G

Pressure Male/Female

Male

Pressure range [bar] [max]

40 bar

Pressure range [bar] [min]

0 bar

Pressure range [psi] [max]

580 psi

Pressure range [psi] [min]

0 psi

Pressure reference

Sealed gauge

Pulse-snubber

No

REACH Candidate List substances

Lead (CAS no. 7439-92-1)

Response time max. [ms]

4 ms

Specification key

MBS 3300-2631-A0GB04-2

Supply voltage [V] DC [max]

32 V

Supply voltage [V] DC [min]

9 V

UL mark

Yes

Material

AISI 316L stainless steel wetted parts

Thread Standard

G 1/4 male (DIN 3852-E / ISO 1179-2, Form E)

Pressure Rating

0 to 40 bar (0 to 580 psi)

Temperature Range

-40 C to +125 C (medium)

IP Rating

IP65

Classification / Approval

ATEX Ex ec IIA T4 Gc; CE; UL Recognized; EAC; RoHS

HS Code

9026.20
