Danfoss BN240CS solenoid valve coil 208-240V AC 50/60Hz clip-on terminal box IP67
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss BN240CS clip-on solenoid coil, 208-240 V AC 50/60 Hz, terminal box (screwed cable entry), IP67, Class H insulation. Encapsulated coil with 13.5 mm clip-on actuator for the EV-series valve range. OEM P/N 018F6832. Valve body ordered separately.
Technical Specifications
- Type
- BN240CS clip-on solenoid coil
- Supply
- 208-240 V AC
- Frequency
- 50/60 Hz
- Power
- 20 W (50 Hz) / 17 W (60 Hz); 43 VA (50 Hz) / 32 VA (60 Hz)
- Connection
- Terminal box (screwed cable entry)
- Enclosure
- IP67
- Insulation
- Class H to IEC 60085
- Ambient
- -40 to +80 °C
- Actuator size
- 13.5 mm, clip-on
- Duty
- continuous
- Design standard
- VDE 0580
- Packing
- multi-pack (24 pc)
- EAN
- 5702428027915
- Fits EV210B / EV212B / EV220B / EV222B / EV224B / EV227B / EV250B / EV251B-series solenoid valve bodies — verify valve series on the datasheet
- Voltage
- 208-240 V
Standards & Compliance
- Material
- Encapsulated coil, Class H insulation
- Temperature Range
- -40 to +80 °C
- IP Rating
- IP67
- HS Code
- 8505.90
Compatibility & Fitment
Clip-on coil — mounts on the EV-series valve actuator (13.5 mm) without tools. Terminal box (screwed cable entry). No prior BN240CS in catalogue. Verify valve series, supply voltage and connection type before ordering. Valve body ordered separately.
