Graco Round Pattern Automatic Fusion Mechanical Purge Gun with 0.070 in (1.8 mm) Ceramic Tip and 0.057 in (1.45 mm) Impingement Port

Graco 248387 Round Pattern Automatic Fusion Mechanical Purge Gun with 0.070 in (1.8 mm) Ceramic Tip and 0.057 in (1.45 mm) Impingement Port, part number 248387. Fusion MP Auto plural-component impingement-mix spray gun, 0.070 in (1.78 mm) fluid orifice, Round spray pattern. Maximum fluid pressure 3500 psi (241 bar). Maximum fluid temperature 200 °F. Compatible material: Polyurethane, Roof Coating, Polyurea, Spray Polyurethane Foam, No-Heat Foam. All values read from the Graco product page (248387 on graco.com).

Brand

Graco Model: Fusion MP Series: Auto Part number: 248387 Type: Spray Gun Compatible material: Polyurethane, Roof Coating, Polyurea, Spray Polyurethane Foam, No-Heat Foam Spray pattern: Round Fluid orifice size: 0.070 in (1.78 mm) Maximum fluid pressure: 3500 psi (241 bar) Maximum air inlet pressure: 130 psi (9 bar) minimum air inlet pressure: 80 psi (5.5 bar) Maximum fluid temperature: 200 °F (93 °C) Maximum flow rate @ pressure: 50 lb/min Sound pressure level: 70 dB(A) Sound power level: 79.9 dB(A) Overall length: 7.6 in (193 mm) Overall height: 3.75 in (95 mm) Overall width: 3.1 in (79 mm)

Pressure Rating

3500 psi (241 bar) max fluid

Temperature Range

up to 200 °F (93 °C)

HS Code

8424.20
