Eff.m.Darw for kont/startere

Eaton Eff.m.Darw for kont/startere (part number EU5C-SWD-PF1-1) is listed in the cBallast industrial catalogue. Sales unit: pcs; Eaton catalogue number: 116309; Depth: 125 mm; Height: 90 mm; Width: 35 mm; Weight: 0.109 kg.

Manufacturer part number (MPN)

EU5C-SWD-PF1-1

EAN / GTIN

4015081160495

Sales unit

pcs

Eaton catalogue number

116309

Depth

125 mm

Height

90 mm

Width

35 mm

Weight

0.109 kg

Certifications

UL Category Control No.: NKCR; IEC/EN 61131-2; CSA; CSA File No.: 2324643; UL; UL File No.: E29184; CSA Class No.: 3211-07; EN 50178

Catalog Notes

SmartWire-DT power supply for additionally feeding the control voltage for motor starters and contactors, as well as for establishing emergency stop groups

Constant acceleration

1 g, 8.4 - 150 Hz, according to IEC/EN 61131-2, Vibrations

Constant amplitude

3,5 mm, 5 - 8.4 Hz, according to IEC/EN 61131-2, Vibrations

Drop and topple

50 mm Drop height, Drop to IEC/EN 60068-2-31

Height of fall (IEC/EN 60068-2-32) - max

0.3 m

Mounting position

As required

Shock resistance

15 g, Mechanical, according to IEC/EN 60068-2-27, Half-sinusoidal shock 11 ms, 9 Impacts

Air pressure

795 - 1080 hPa (operation)

Ambient operating temperature - max

55 °C

Ambient storage temperature - max

70 °C

Ambient operating temperature - min

-25 °C

Ambient storage temperature - min

-40 °C

Climatic proofing

Dry heat to IEC 60068-2-2; Damp heat, constant, to IEC 60068-2-3

Environmental conditions

Condensation: prevent with appropriate measures

Operating temperature - max

55 °C

Operating temperature - min

-25 °C

Relative humidity

5 - 95 % (non-condensing, IEC/EN 60068-2-30)

Connection

2 x SmartWire-DT blade terminal SWD4-8MF2

Connection to SmartWire-DT

Yes

Connection type

SWD: 2 x plug, 8-pole; Push in terminals, Supply voltage

Protocol

Other bus systems

Static heat dissipation, non-current-dependent Pvs

1 W

Power loss

Normally 1 W

Rated control supply voltage

24 V DC (UAUX, -15 %/+20 %)

Rated operational voltage

Typically UAUX -0.2 V (for 24 V DC slaves)

Short-circuit protection

No, external fuse FAZ Z3, Supply voltage UAux

Supply current

3 A, Imax, Supply voltage UAux

Supply voltage at DC - max

28.8 VDC

Supply voltage at DC - min

20.4 VDC

Air discharge

8 kV, according to IEC 61131-2, level 3, ESD

Burst impulse

2 kV, Supply cable, according to IEC/EN 61131-2, Level 3; 1 kV, SmartWire-DT cable, according to IEC/EN 61131-2, Level 3

Contact discharge

4 kV, according to IEC/EN 61131-2, Level 2, ESD

Electromagnetic fields

3 V/m at 1.4 - 2 GHz (according to IEC/EN 61131-2:2008); 10 V/m at 80 - 1000 MHz (according to IEC/EN 61131-2:2008); 1 V/m at 2.0 - 2.7 GHz (according to IEC/EN 61131-2:2008)

Radiated RFI

10 V (IEC/EN 61131-2:2008, Level 3)

Radio interference class

Class A (EN 55011)

Surge rating

0.5 kV, Supply cables/CAN/DP bus cable, Surge power cables, Surge (IEC/EN 61131-2:2008, Level 1), EMC

Electric connection type

Flat plug-in connection

Features

Fieldbus connection over separate bus coupler possible; Fieldbus connection over separate bus coupler possible

Fitted with

Power supply module

Functions

For feeding control voltage in order to connect additional motor starters and contactors to the SmartWire-DT ribbon cable; For the formation of emergency switching off groups for motor starters and contactors

Degree of protection

IP20

Mounting method

Rail mounting possible; Top-hat rail fixing (according to IEC/EN 60715, 35 mm); Wall mounting/direct mounting

Overvoltage category

II

Pollution degree

2

Product category

SmartWire-DT accessories

Residual ripple

≤ 5 % (input voltage)

Suitable as

Segment module

Terminal capacity

0.2 - 1.5 mm², solid; 24 - 16 AWG, solid or stranded; 0.25 - 1.5 mm², flexible with ferrule

Voltage type

DC

Explosion safety category for dust

None

Explosion safety category for gas

None

Potential isolation

Supply voltage UAUX: no

Protection against polarity reversal

Yes; Yes, for supply voltage (Siemens MPI optional)

Certified for UL hazardous location division 1

No

Certified for UL hazardous location division 2

No

Certified for UL hazardous location group A (acetylene)

No

Certified for UL hazardous location group B (hydrogen)

No

Certified for UL hazardous location group C (ethylene)

No

Certified for UL hazardous location group D (propane)

No

Certified for UL hazardous location group E (metal dusts)

No

Certified for UL hazardous location class I

No

Certified for UL hazardous location class II

No

Certified for UL hazardous location class III

No

Supporting protocol for EtherCAT

No

Supply voltage DC

20.4–28.8 V

Number of HW-interfaces other

1

With optical interface

No

Supporting protocol for TCP/IP

No

Supporting protocol for PROFIBUS

No

Supporting protocol for CAN

No

Supporting protocol for INTERBUS

No

Supporting protocol for ASI

No

Supporting protocol for KNX

No

Supporting protocol for Modbus

No

Supporting protocol for Data-Highway

No

Supporting protocol for DeviceNet

No

Supporting protocol for SUCONET

No

Supporting protocol for LON

No

Supporting protocol for PROFINET IO

No

Supporting protocol for PROFINET CBA

No

Supporting protocol for SERCOS

No

Supporting protocol for Foundation Fieldbus

No

Supporting protocol for EtherNet/IP

No

Supporting protocol for AS-Interface Safety at Work

No

Supporting protocol for DeviceNet Safety

No

Supporting protocol for INTERBUS-Safety

No

Supporting protocol for PROFIsafe

No

Supporting protocol for SafetyBUS p

No

Supporting protocol for other bus systems

Yes

Radio standard Bluetooth

No

Radio standard WLAN 802.11

No

Radio standard GPRS

No

Radio standard GSM

No

Mobile communications standard 3G (UMTS)

No

System accessory

Yes

Type of electric connection

Flat plug-in connection

With potential separation

No

With power supply module

Yes

Suitable as segment module

Yes

Remote module

No

Fieldbus connection over separate bus coupler possible

Yes

Bus diagnosis possible

No

Suitable for rail mounting

Yes

Wall mounting/direct mounting

Yes

Front built-in possible

No

Rack-assembly possible

No

Suitable for safety functions

No

SIL according to IEC 61508

None

Performance level according to EN ISO 13849-1

None

Appendant operation agent (Ex ia)

No

Country of origin

Germany

HS Code

8538.90
