Danfoss SVA-S 80 straightway shut-off (stop) valve, 80 mm (3 in) butt weld EN 10220, cap, steel, 52 bar
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss SVA-S 80 straightway shut-off (stop) valve for industrial-refrigeration line service, code 148B5911. Size 3 in (80 mm), with butt weld inlet and outlet to EN 10220. Carbon-steel Flexline body for ammonia (R717), CO2 (R744) and HFC/HCFC refrigerant service. Maximum working pressure 52 bar (754 psig); media temperature range -60 to 150 C (-76 to 302 F); Kv 152 m3/h (Cv 176.32 gal/min). Straightway body places inlet and outlet in line. This is the cap-closed variant (sealing cap in place of a handwheel) for set-and-seal stop duty. Part of the Danfoss SVL Flexline program; specifications per Danfoss store code 148B5911.
Technical Specifications
- Type
- SVA-S 80 (shut-off / stop valve)
- Code number
- 148B5911
- Series
- SVL Flexline (SVA-S)
- Function
- Manual shut-off (stop) valve
- Nominal size
- DN80 — 3 in (80 mm)
- Direction
- Straightway
- Equipment
- Cap
- Neck
- Standard (SVA-S)
- Flow direction
- Bi-flow
- Inlet connection type
- Butt weld
- Outlet connection type
- Butt weld
- Connection standard
- EN 10220
- Connection size
- 3 in (80 mm)
- Body material
- Steel
- Connection material
- Steel
- Maximum working pressure
- 52 bar (754 psig)
- Media temperature range
- -60 to 150 C (-76 to 302 F)
- Kv value
- 152 m3/h
- Cv value
- 176.32 gal/min
- Applicable media
- HCFC, HFC, R717 (ammonia), R744 (CO2)
- Conformity assessment
- PED 2014/68/EU, Category II
- Approvals
- CE, EAC
- EAN
- 5702428468077
Standards & Compliance
- Standard
- EN 10220
- Size / Series
- 80 mm
- Material
- Steel
- Pressure Rating
- 52 bar
- Temperature Range
- -60 to 150 C
- HS Code
- 8481.80
Compatibility & Fitment
Danfoss SVL Flexline SVA-S 80 shut-off valve. Select by nominal size (80 mm / 3 in), direction (straightway), operation (cap vs handwheel) and connection (butt weld EN 10220). EN 10220 and ASME weld-end variants are separate codes — confirm the mating pipe standard before ordering.
