Danfoss MBT 5260 temperature sensor, Pt 1000 1000 ohm, 40 mm insertion, G 1/2, M12 4-Pin connector
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss MBT 5260 insertion temperature sensor, code 084Z2295 (type designation MBT 5260-3100-040-820). Insertion RTD with an M12 x 1 4-pin plug connector for cooling water, oil and refrigeration circuits in general industry and marine installations. Standardized Pt 1000 platinum element (1000 ohm at 0 C), Class B tolerance per EN 60751. Insertion length 40 mm; G 1/2 male (ISO 228-1-A) process connection; AISI 316 Ti stainless-steel protection tube, 8 mm diameter. Measuring range -20 to +90 C (-4 to +194 F); resistance (ohm) output. M12 x 1 male 4-pin connector per IEC 61076-2-101; IP65 enclosure per IEC 60529. CE marked.
Technical Specifications
- Type
- MBT 5260 (insertion temperature sensor, M12 connector)
- Type designation
- MBT 5260-3100-040-820
- Code number
- 084Z2295
- Sensor element
- Pt 1000 platinum resistance (1000 ohm at 0 C)
- Tolerance class
- Class B per EN 60751
- Insertion length
- 40 mm
- Process connection
- G 1/2 male (ISO 228-1-A)
- Protection tube
- AISI 316 Ti stainless steel, 8 mm diameter
- Measuring range
- -20 to +90 C (-4 to +194 F)
- Output signal
- Ohm (resistance)
- Electrical connection
- M12 x 1 male, 4-pin, IEC 61076-2-101
- Enclosure rating
- IP65 per IEC 60529
- Packing quantity
- 20 pc
- Net weight
- 0.131 kg
- Approvals
- CE
- EAN
- 5702428876063
- Product group
- Sensors
- Ambient temperature max. [°C]
- 90 °C
- Ambient temperature max. [°F]
- 194 °F
- Approval
- CE
- CE mark
- Yes
- China RoHS compliance
- Out of scope
- Connection material
- Stainless steel
- Connection type
- G
- EEE category
- 5 small equipment (any external dimension < 50 cm)
- Electrical conn. Male/Female
- Male
- Electrical connection size
- 4 pin
- Electrical connection standard
- IEC 61076-2-101
- Enclosure rating IP
- IP65
- EU RoHS compliance
- Yes with exemptions
- EU RoHS exemption clause
- 6(c)
- In scope of WEEE
- Yes
- Insertion length [in]
- 1.57 in
- Insertion length [mm]
- 40 mm
- Insertion type
- Fixed
- Measuring range [°C] [max]
- 90 °C
- Measuring range [°C] [min]
- -20 °C
- Measuring range [°F] [max]
- 194 °F
- Measuring range [°F] [min]
- -4 °F
- Process connection Male/Female
- Male
- Process connection material
- Stainless steel
- Process connection size
- 1/2
- Process connection standard
- ISO 228-1-A
- Process connection type
- G
- Protection tube diameter [in]
- 0.315 in
- Protection tube diameter [mm]
- 8 mm
- Protection tube material
- AISI 316 TI
- REACH Candidate List substances
- Lead (CAS no. 7439-92-1)
- Sensor elem. resistance [Ohm]
- 1000 Ohm
- Sensor element [pc]
- 1 pc
- Sensor element standard
- EN 60751
- Sensor element tolerance
- Class B
- Sensor element type
- Pt
- Sensor Insert
- Fixed
- Temperature range [°C] [max]
- 90 °C
- Temperature range [°C] [min]
- -20 °C
- Temperature range [°F] [max]
- 194 °F
- Temperature range [°F] [min]
- -4 °F
- Wires [pcs]
- 2 pc
Standards & Compliance
- Size / Series
- 40 mm insertion
- Material
- AISI 316 Ti stainless steel
- Thread Standard
- ISO 228-1-A
- Temperature Range
- -20 to +90 C (-4 to +194 F)
- IP Rating
- IP65
- HS Code
- 9025.19
Compatibility & Fitment
MBT 5260 sensor with M12 x 1 4-pin plug. Confirm the mating M12 cordset, insertion length (40 mm), process thread (G 1/2) and Pt 1000 wiring match the controller input before ordering.
