Danfoss MBT 5250 temperature sensor, Pt 1000 platinum resistance, 200 mm, G 1/2 process connection (code 084Z2257)
Danfoss · Sensors & Instrumentation · Temperature Sensors
Danfoss MBT 5250 temperature sensor (type designation MBT 5250-0100-200-220), code 084Z2257. Sensor element Pt 1000 platinum resistance (1000 ohm at 0 C), Class B per EN 60751. Insertion length 200 mm insertion; G 1/2 male (ISO 228-1-A) process connection; AISI 316 Ti stainless steel. Measuring range -50 to +200 C (-58 to +392 F); output Ohm (resistance). Electrical connection: Angular connector, Pg 11 (EN 175301-803-A). Enclosure IP65 per IEC 60529. CE marked.
Specifications
- Part number
- 084Z2257
- HS code
- 9025.19
- Material
- AISI 316 Ti stainless steel
- Temperature range
- -50 to +200 C (-58 to +392 F)
- IP rating
- IP65
- Standard size
- 200 mm insertion
- Thread standard
- ISO 228-1-A
Compatibility
MBT 5250 temperature sensor. Confirm insertion length (200 mm insertion), process thread (G 1/2) and element (Pt 1000 platinum resistance) match the pocket and controller input.
Standards
- EN 60751
- ISO 228-1-A
- EN 175301-803-A
- IEC 60529
