Danfoss KP35 pressure switch, -0.2–7.5 bar (6 inHg–109 psig), 0.7–4 bar (10–58 psi) differential, automatic reset, SPDT, 1/4-18 NPT, IP30
Danfoss · Sensors & Instrumentation · Pressure Switches
Danfoss KP35 pressure switch, code 060-500066. Regulation range -0.2–7.5 bar (6 inHg–109 psig) with 0.7–4 bar (10–58 psi), adjustable and automatic reset, SPDT snap-action contact system. Connection 1/4-18 NPT (female). Max working pressure 17 bar (245 psig). IP30 enclosure. RINA, RMRS type approval. EAN 5702423148578.
Specifications
- Part number
- 060-500066
- HS code
- 9026.20
- Material
- Steel housing; SPDT contacts; bellows sensing element
- Pressure rating
- max working pressure 17 bar (245 psig)
- Temperature range
- -40 to +70 °C
- IP rating
- IP30
- Thread standard
- 1/4-18 NPT (female)
Compatibility
NPT-connection KP35 low-pressure switch with wide -0.2–7.5 bar range for refrigeration and industrial control.
Standards
- IEC 60529 (enclosure IP rating)
- ANSI/ASME B1.20.1 (NPT thread)
- EU RoHS
Approvals
- CE
- UL
- RINA
- RMRS
- EAC
- CCC
- CMIM
- EU RoHS
