Danfoss ICS 100 pilot-operated servo valve, butt weld 100 mm (4 in)
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss ICS 100 pilot-operated servo valve (code 027H7122), a main valve of the ICV Flexline modular industrial-refrigeration platform. Butt-weld 100 mm (4 in) connections; Kv 142 m3/h, maximum working pressure 52 bar (754 psig). The valve function (constant pressure, constant temperature, solenoid stop, etc.) is set by the pilot valve(s) fitted to the top cover. Suitable for R717 (ammonia), R744 (CO2), R22, R134a, R404A, R407C, R410A, R507A and the wider HFC/HFO range listed by Danfoss for this code. CE 0045 (PED), TÜV, UL and EAC. Pilot valves and function module ordered separately.
Technical Specifications
- Type
- ICS 100 pilot-operated servo valve
- Code number
- 027H7122
- Connection type
- butt weld
- Connection size
- 100 mm (4 in)
- Kv value
- 142 m3/h
- Maximum working pressure
- 52 bar (754 psig)
- Valve operation
- pilot-operated servo valve (function set by pilots)
- Refrigerants
- R717, R744, R22, R134a, R404A, R407C, R410A, R507A and wider HFC/HFO range
- Net weight
- 44.66 kg; gross weight: 52.6 kg
- Approvals
- CE 0045 (PED), EAC, TUV, UL
- EAN
- 5702428229753
- Brand
- ICV Flexline
- Product group
- Press. and temp. regul. valves
- Direction
- Straightway
- Body material
- Steel
- Connection material
- Steel
- Connection standard
- ASME B 36.10M SCHEDULE 40
- Inlet connection size
- 100.00 mm
- Inlet connection type
- Butt weld
- Outlet connection size
- 100.0 mm
- Outlet connection type
- Butt weld
- Cv value
- 164.720 gal/min
- Max. working pressure
- 52.0 bar
- Temperature range
- -60 °C to 120 °C
- Fluid Group
- 1
- PED category
- II
- UL approval file name
- REFRIGERANT VALVE 53R0
- UL mark
- Yes
- REACH candidate-list substances
- No
- Equipment
- Cap
- Ext pilot pressure connection
- Weld nipple (P2 Port)
- Flow direction indicator
- Embossed 1-way arrow
- Manual operation option
- Manual open spindle
- Opening configuration
- Closed (delta p=0 bar); Full open (delta p≥0.2 bar); PropOpen (delta p=0.07-0.2bar)
- Pilot connection configuration
- P: Parallel connection; SI-SII: Serial connection
- Pressure gauge connection
- Int. thread with blind plug
- Side branch connection
- 3/8
- Side branch connection type
- NPT
- Surface coating
- Zn (TLP)
- Top cover
- 3 function modules
Standards & Compliance
- Pressure Rating
- 52 bar
- HS Code
- 8481.80
Compatibility & Fitment
ICS 100 servo main valve. Confirm Kv (142 m3/h) and select the pilot valve(s) for the required function; top cover / function module and pilots are ordered separately.
