Danfoss ICS 150 pilot-operated servo valve, butt weld 150 mm (6 in), with 3/8 NPT auxiliary side connection
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss ICS 150 pilot-operated servo valve (code 027H7162), a main valve of the ICV Flexline modular industrial-refrigeration platform. Butt-weld 150 mm (6 in) connections, with 3/8 NPT auxiliary side connection; Kv 354 m3/h, maximum working pressure 52 bar (754 psig). The valve function (constant pressure, constant temperature, solenoid stop, etc.) is set by the pilot valve(s) fitted to the top cover. Suitable for R717 (ammonia), R744 (CO2), R22, R134a, R404A, R407C, R410A, R507A and the wider HFC/HFO range listed by Danfoss for this code. CE 0045 (PED), TÜV, UL and EAC. Pilot valves and function module ordered separately.
Technical Specifications
- Type
- ICS 150 pilot-operated servo valve
- Code number
- 027H7162
- Connection type
- butt weld
- Connection size
- 150 mm (6 in)
- Side connection
- with 3/8 NPT auxiliary side connection
- Kv value
- 354 m3/h
- Maximum working pressure
- 52 bar (754 psig)
- Valve operation
- pilot-operated servo valve (function set by pilots)
- Refrigerants
- R717, R744, R22, R134a, R404A, R407C, R410A, R507A and wider HFC/HFO range
- Net weight
- 128 kg; gross weight: 132.2 kg
- Approvals
- CE 0045 (PED), EAC, TUV, UL
- EAN
- 5702428229623
- Product group
- Press. and temp. regul. valves
- Approval
- CE 0045
- Body material
- Steel
- China RoHS compliance
- Yes
- Connection Code
- (2002:S40:150)
- Connection material
- Steel
- Connection standard
- ASME B 36.10M SCHEDULE 40
- Cv value [gal/min]
- 410.64 gal/min
- Direction
- Straightway
- Equipment
- Cap
- EU RoHS compliance
- Yes
- Ext pilot pressure connection
- Weld nipple (P2 Port)
- Flow direction indicator
- Embossed 1-way arrow
- Fluid Group
- 1
- Inlet connection size [in]
- 6 in
- Inlet connection size [mm]
- 150 mm
- Inlet connection type
- Butt weld
- Kv value [m³/h]
- 354 m³/h
- Manual operation option
- Manual open spindle
- Max. Working Pressure [bar]
- 52 bar
- Max. Working Pressure [psig]
- 754 psig
- Opening configuration
- Closed (delta p=0 bar)
- Outlet connection size [in]
- 6 in
- Outlet connection size [mm]
- 150 mm
- Outlet connection type
- Butt weld
- PED category
- III
- Pilot connection configuration
- P: Parallel connection
- Pressure gauge connection
- Int. thread with blind plug
- REACH Candidate List substances
- No
- Side branch connection [in]
- 3/8
- Side branch connection type
- NPT
- Surface coating
- Zn (TLP)
- Temperature range [°C] [max]
- 120 °C
- Temperature range [°C] [min]
- -60 °C
- Temperature range [°F] [max]
- 248 °F
- Temperature range [°F] [min]
- -76 °F
- Top cover
- 3 function modules
- UL approval file name
- REFRIGERANT VALVE 53R0
- UL mark
- Yes
- Valve version
- Standard version
Standards & Compliance
- Pressure Rating
- 52 bar
- HS Code
- 8481.80
Compatibility & Fitment
ICS 150 servo main valve. Confirm Kv (354 m3/h) and select the pilot valve(s) for the required function; top cover / function module and pilots are ordered separately.
