Danfoss ICM 125 motor-operated valve, steel, butt weld 125 mm (5 in)
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss ICM 125 motor-operated valve, steel (code 027H7151), a modulating main valve of the ICV Flexline platform driven by an ICAD electric actuator for stepless regulation of pressure, capacity, liquid level or temperature. Butt-weld 125 mm (5 in) connections; Kv 223 m3/h, maximum working pressure 52 bar (754 psig). Suitable for R717 (ammonia), R744 (CO2), R22, R134a, R404A, R407C, R410A, R507A and the wider HFC/HFO range listed by Danfoss for this code. CE 0045 (PED), TÜV, UL and EAC. The ICAD 600A/1200A actuator is ordered separately.
Technical Specifications
- Type
- ICM 125 motor-operated valve
- Code number
- 027H7151
- Body material
- steel
- Connection type
- butt weld
- Connection size
- 125 mm (5 in)
- Kv value
- 223 m3/h
- Maximum working pressure
- 52 bar (754 psig)
- Valve operation
- motor (ICAD actuator) operated
- Refrigerants
- R717, R744, R22, R134a, R404A, R407C, R410A, R507A and wider HFC/HFO range
- Net weight
- 72 kg; gross weight: 79.8 kg
- Approvals
- CE 0045 (PED), EAC, TUV, UL
- EAN
- 5702428229678
- Product group
- Press. and temp. regul. valves
- Actuator system
- ICAD motor, magnet coupling
- Approval
- CE 0045
- China RoHS compliance
- Yes
- Comments
- ICV 125 125 ANSI
- Connection Code
- (2002:S40:125)
- Connection material
- Steel
- Connection standard
- ASME B 36.10M SCHEDULE 40
- Cv value [gal/min]
- 260 gal/min
- Direction
- Straightway
- Equipment
- Cap
- EU RoHS compliance
- Yes
- Flow direction indicator
- Embossed 1-way arrow
- Fluid Group
- 1
- Inlet connection size [in]
- 5 in
- Inlet connection size [mm]
- 125 mm
- Inlet connection type
- Butt weld
- Kv value [m³/h]
- 223 m³/h
- Lubricants compatibility
- Oilfree applications
- Manual operation option
- Via ICAD setting
- Max. Working Pressure [bar]
- 52 bar
- Max. Working Pressure [psig]
- 754 psig
- MaxOPD [bar]
- 20 bar
- MaxOPD [psig]
- 271 psig
- Oil free refrigerants
- R1234ze(E)
- Open/close time [s]
- 35 s
- Outlet connection size [in]
- 5 in
- Outlet connection size [mm]
- 125 mm
- Outlet connection type
- Butt weld
- PED category
- III
- REACH Candidate List substances
- No
- Surface coating
- Zn (TLP)
- Temperature range [°C] [max]
- 120 °C
- Temperature range [°C] [min]
- -60 °C
- Temperature range [°F] [max]
- 248 °F
- Temperature range [°F] [min]
- -76 °F
- UL approval file name
- REFRIGERANT VALVE 53R0
- UL mark
- Yes
- Valve version
- Standard version
Standards & Compliance
- Pressure Rating
- 52 bar
- HS Code
- 8481.80
Compatibility & Fitment
ICM 125 modulating motor valve. Requires an ICAD 600A/1200A actuator (ordered separately); confirm Kv (223 m3/h) and MWP (52 bar) for your duty.
