Danfoss FIA 100 straightway strainer housing, 100 mm (4 in) butt weld EN 10220, steel, 52 bar (code 148B6007)
Danfoss · HVAC & Refrigeration · Filters & Driers
Danfoss FIA 100 straightway strainer housing for industrial refrigeration, code 148B6007. Steel body with butt weld connections to EN 10220, nominal size 100 mm (4 in), used to protect valves, pumps and compressors from pipe-scale and debris. Maximum working pressure 52 bar (754 psig); media temperature range -60 to 150 C (-76 to 302 F). Flow coefficient with standard µ150 plain insert Kv 124.2 m3/h (Cv 143.6 gal/min); higher Kv with pleated inserts. Filter insert ordered separately. Part of the Danfoss SVL Flexline programme; for R717 (ammonia), R744 (CO2) and fluorinated refrigerants.
Specifications
- Part number
- 148B6007
- HS code
- 8421.39
- Material
- Steel
- Pressure rating
- 52 bar
- Temperature range
- -60 to 150 C
- Standard
- EN 10220
- Standard size
- 100 mm
Compatibility
Danfoss SVL Flexline FIA 100 strainer housing. Select by direction (straightway) and connection standard (EN 10220); order the filter insert (µ150 / µ250 / µ500, plain or pleated) separately. Shares the SVL Flexline platform with SVA-S/SVA-L, SCA-X/CHV-X and REG valves of the same nominal size.
Approvals
