Danfoss SVL 100 multifunction valve body, straightway, 100 mm (4 in) butt weld EN 10220, steel, 52 bar (code 148B6015)
Danfoss · HVAC & Refrigeration · Globe Valves
Danfoss SVL 100 multifunction valve body for industrial refrigeration, code 148B6015. Bare straightway valve housing with butt weld connections to EN 10220, nominal size 100 mm (4 in), steel body. The SVL housing is the common platform onto which SVA-S/SVA-L shut-off, SCA-X/CHV-X stop-check and FIA strainer function modules are fitted. Maximum working pressure 52 bar (754 psig); media temperature range -60 to 150 C (-76 to 302 F). Bi-flow. For R717 (ammonia), R744 (CO2) and fluorinated refrigerants and their oils.
Specifications
- Part number
- 148B6015
- HS code
- 8481.90
- Material
- Steel
- Pressure rating
- 52 bar
- Temperature range
- -60 to 150 C
- Standard
- EN 10220
- Standard size
- 100 mm
Compatibility
Danfoss SVL Flexline 100 steel valve housing. Accepts SVA-S/SVA-L shut-off, SCA-X/CHV-X stop-check and FIA strainer function modules of the same nominal size. EN 10220 and ASME weld-end preparations are not interchangeable — the ASME cell of this size is code 148B6017 (straightway). Select the angleway version as code 148B6014.
