Danfoss CVPE-L constant-pressure pilot valve, hydrocarbon, low pressure -0.66 to 7 bar, for ICS servo-operated main valves
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss CVPE-L constant-pressure pilot valve, code 027B1020 — the hydrocarbon (HC) service version of the CVP constant-pressure pilot for ICS servo-operated main valves. Mounted in the pilot channel of an ICS main valve, it holds a constant pressure at the main-valve inlet independent of the downstream pressure. Low-pressure regulating range -0.66 to 7 bar (19.5 inHg to 102 psig). Flow coefficient Kv 0.4 m3/h (Cv 0.46). Maximum working pressure 52 bar (754 psig); media temperature range -60 to 120 C (-76 to 248 F). Zn (TLP) surface coating; supplied as a 6-piece multipack with gasket. Approved for hydrocarbon refrigerants R1270, R170, R290, R600, R600a. PED Art. 4 par. 3.
Technical Specifications
- Type
- CVPE-L (constant-pressure pilot valve, hydrocarbon)
- Code number
- 027B1020
- Series
- CVP / CVPP / CVC / CVE / EVM / CVH pilot valves
- Function
- Constant-pressure pilot — holds constant inlet pressure
- Valve version
- Low pressure, hydrocarbon (HC)
- Regulating range
- -0.66 to 7 bar (19.5 inHg to 102 psig)
- Kv value
- 0.4 m3/h
- Cv value
- 0.46 gal/min
- Maximum working pressure
- 52 bar (754 psig)
- Media temperature range
- -60 to 120 C (-76 to 248 F)
- Surface coating
- Zn (TLP)
- Net weight
- 1.037 kg
- Gross weight
- 1.617 kg
- Packing format
- Multi pack (6 pc)
- Parts included
- Gasket
- Refrigerants
- R1270, R170, R290, R600, R600a
- PED category
- Art. 4, par. 3
- Approvals
- EAC
- EAN
- 5702428680905
- Product group
- Press. and temp. regul. valves
- Approval
- EAC
- China RoHS compliance
- Yes
- Cv value [gal/min]
- 0.46 gal/min
- EU RoHS compliance
- Yes
- Fluid Group
- 1
- Kv value [m³/h]
- 0.4 m³/h
- Max. Working Pressure [bar]
- 52 bar
- Max. Working Pressure [psig]
- 754 psig
- Pressure range [bar] Pe [max]
- 7 bar
- Pressure range [bar] Pe [min]
- -0.66 bar
- Pressure range [psig] Pe [max]
- 102 psig
- Pressure range [psig] Pe [min]
- 19.5 psig
- REACH Candidate List substances
- No
- Regulation range
- 19.5inHg - 102psig
- Temperature range [°C] [max]
- 120 °C
- Temperature range [°C] [min]
- -60 °C
- Temperature range [°F] [max]
- 248 °F
- Temperature range [°F] [min]
- -76 °F
Standards & Compliance
- Size / Series
- -0.66 to 7 bar
- Material
- Steel
- Pressure Rating
- 52 bar
- Temperature Range
- -60 to 120 C
- HS Code
- 8481.80
Compatibility & Fitment
Hydrocarbon (HC) variant of the CVP-L pilot. Mounts in the pilot channel of Danfoss ICS servo-operated main valves. Pressure-range sibling: CVPE-M medium 4 to 28 bar (027B1021). Confirm the ICS valve size and pilot arrangement before ordering.
Product Documentation
More from Danfoss
Danfoss
Danfoss CVPE-M constant-pressure pilot valve, hydrocarbon, medium pressure 4 to 28 bar, for ICS servo-operated main valves
027B1021
Danfoss
Danfoss EVM (NO) normally-open solenoid pilot valve, 1.8 mm orifice, for ICS servo-operated main valves
027B1130
Danfoss
Danfoss SV 3E float valve, hydrocarbon, modulating liquid-level regulating valve, Kv 0.14, MWP 28 bar
027B0081
Danfoss
Danfoss SV 1 float valve, modulating liquid-level regulating valve, Kv 0.06, MWP 28 bar
027B2021
Danfoss
Danfoss SV 3 float valve, modulating liquid-level regulating valve, Kv 0.14, MWP 28 bar
027B2023
Danfoss
Danfoss SV 4 float valve, modulating liquid-level regulating valve, Kv 0.23, MWP 28 bar
027B2024
Danfoss
Danfoss SV 5 float valve, modulating liquid-level regulating valve, Kv 0.31, MWP 28 bar
027B2025
Danfoss
Danfoss SV 6 float valve, modulating liquid-level regulating valve, Kv 0.43, MWP 28 bar
