Danfoss CHANGEOVER6 — CHANGEOVER6 Actuator for NovoCon S, with open-end wires
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss ChangeOver6 digital electric actuator, OEM order code 003Z8522. ChangeOver6 Actuator for NovoCon S, with open-end wires. Drives Danfoss AB-QM pressure-independent balancing & control valves (AB-QM). Supply voltage 24 V. Control / communication signals: 2-point. Operating torque 10 N-m. Ingress protection IP53. Mounts on the AB-QM valve neck and modulates flow to a controller setpoint. Technical data quoted verbatim from store.danfoss.com (code 003Z8522). EAN 5702428966801. HS 9032.89.
Technical Specifications
- Brand
- Danfoss
- Part number
- 003Z8522
- Code number
- 003Z8522
- Valve compatibility
- AB-QM
- Type
- ChangeOver6 actuators
- Product group
- Other valves
- Description
- ChangeOver6 Actuator for NovoCon S, with open-end wires
- Control signal type
- 2-point
- Operating torque [Nm]
- 10 N-m
- Supply voltage [V] AC
- 24 V
- IP protection class
- IP53
- Cable length [m]
- 1.5 m
- Usage
- for NovoCon
- Contains batteries
- No
- REACH Candidate List substances
- No
- EU RoHS compliance
- Yes with exemptions
- EPD available
- Yes
- Net weight
- 0.65 Kilogram
- Gross weight
- 0.726 Kilogram
- Volume
- 2 Liter
- EAN
- 5702428966801
- HS code
- 9032.89
Standards & Compliance
- IP Rating
- IP53
- HS Code
- 9032.89
Compatibility & Fitment
Digital actuator for Danfoss AB-QM pressure-independent balancing valves, size range AB-QM. Match the actuator to the AB-QM valve DN before ordering — NovoCon S covers DN10-32, NovoCon M DN40-100, NovoCon L DN125-150, NovoCon XL DN200-250. Confirm the control signal (2-point) matches your BMS.
