Danfoss MBS 4251 Pressure Transmitter 0 to 60 bar 4-20 mA (060G6198)
Danfoss · Sensors & Instrumentation · Pressure Transmitters
Danfoss MBS 4251 pressure transmitter (intrinsically safe), genuine OEM code 060G6198. Measuring range 0 to 60 bar (0 to 870 psi), 4-20 mA (2-wire), 316L stainless steel wetted parts. 1/4-18 NPT (male) pressure connection; Angular connector Pg 9, EN 175301-803-A. MBS 4251 intrinsically safe transmitter, 0 to 60 bar, 1/4-18 NPT port and angular Pg 9 connector; for hazardous-area service. EAN 5702428488105. P/N 060G6198.
Specifications
- Part number
- 060G6198
- HS code
- 9026.20
- Material
- AISI 316L stainless steel wetted parts
- Pressure rating
- 0 to 60 bar
- Temperature range
- -40 to 125°C
- IP rating
- IP65
- Thread standard
- ANSI/ASME B1.20.1
Compatibility
Intrinsically safe (Ex ia IIC) — install with a certified barrier/isolator. NPT 1/4-18 process port; two-wire current loop 10-28 V DC.
Standards
- IEC 61326
- IEC 61298-2
- IEC 60770
- EN 61326-1
