Jumper; 3-Way; insulated; light gray (2004-403)
Pricing
Request a quote
We reply within 24 hours
Product Description
WAGO 2004-403 Manufacturer description: Jumper; 3-way; insulated; light gray. Insulated jumper link, 3-pole, 4mm², 32A. Light grey.
Technical Specifications
- Manufacturer part number (MPN)
- 2004-403
- EAN / GTIN
- 4017332068734
- Sales unit
- pcs
- Package quantity
- 25 pcs
- Number of spacings
- 3 -fach
- Rated current
- 32 A
- Width
- 16.5 mm / 0.65 inches
- Height
- 4.1 mm / 0.161 inches
- Depth
- 19 mm / 0.748 inches
- Color
- light gray
- Material group
- I
- Insulation material (main housing)
- Polyamide (PA66)
- Flammability class per UL94
- V0
- Fire load
- 0.009 MJ
- Weight
- 2.2 g
- Product Group
- 22 (TOPJOB S)
- PU (SPU)
- 25 pcs
- Packaging type
- Bag
- Country of origin
- DE
- Customs tariff number
- 85366990990
- UNSPSC
- 39,121,421
- eCl@ss 10.0
- 27-14-11-40
- eCl@ss 9.0
- 27-14-11-40
- ETIM 9.0
- EC000489
- ETIM 10.0
- EC000489
- ECCN
- NO US CLASSIFICATION
- RoHS Compliance Status
- Compliant,No Exemption
- Processing temperature (min.)
- -35. °C
- Processing temperature (max.)
- 85. °C
- Processing temperature
- -35 … +85 °C
- Continuous operating temperature from
- -60 °C
- Continuous operating temperature up to
- 105 °C
- Continuous operating temperature
- -60 … +105 °C
- EAN
- 4055143699761
- MPN
- 2004-403
- Mounting method
- Pluggable
- Colour
- Grey
- Model
- Transverse connector
- Insulated
- Yes
- Rated voltage
- 800 V
- Modular spacing
- 6.2 mm
- Number of bridged clamps
- 3
- With contact protection
- Yes
- Rated current In
- 32 A
- Explosion-tested version 'Ex e'
- Yes
Standards & Compliance
- HS Code
- 8536.69
Cross References
- EAN 4017332068734
- SAP 1000064784
- Code 8731478
Product Documentation
