Siemens 5SM2342-6KK01 Residual Current Block for MCBs 4P 40 A 30 mA
Pricing
Request a quote
We reply within 24 hours
Product Description
Siemens 5SM2342-6KK01 residual current block for use with miniature circuit breakers (MCBs), 4-pole, 40 A, 30 mA. Type A leakage current with short-time delay and anti-nuisance tripping; IP20 protection for indoor DIN-rail installation. Accepts solid or stranded conductors from 1.5 to 25 mm².
Technical Specifications
- Manufacturer part number (MPN)
- 5SM2342-6KK01
- EAN / GTIN
- 4001869281414
- HS code
- 8536.90
- Sales unit
- pcs
- Nominal voltage
- 400 V
- Nominal current
- 40 A
- Rated fault current adjustable
- No
- Rated fault current
- 30 A
- Delay adjustable
- No
- Number of poles
- 4
- Leakage current type
- A
- Surge current capacity
- 4000 kA
- Frequency
- 50/60 Hz
- Rated insulation voltage Ui
- 460 V
- Rated impulse withstand voltage Uimp
- 3 kV
- Connectable conductor cross section solid-core
- 1.5–25 mm²
- Connectable conductor cross section multi-wired
- 1.5–25 mm²
- Anti-nuisance tripping version
- Yes
- With interlocking device
- No
- Degree of protection (IP)
- IP20
- Pollution degree
- 2
- Ambient temperature during operating
- -25–45 °C
- Country of origin
- Czechia
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 4001869281414
- SAP 1000411922
- Code 8491023
Product Documentation
More from Siemens
Siemens
Siemens SIMATIC ET 200MP IM155-5 DP ST
6ES7155-5BA00-0AB0
Siemens
Siemens SCALANCE X, SFP991-1LH+
6GK5991-1AE00-8AA0
Siemens
Siemens Sentron Load-break switch, 32 A, 3-Pole, 440 V AC, 10 kA Icw
5TL1332-0
Siemens
Siemens SINAMICS V20,1AC 230V 1
6SL3210-5BB211BV1
Siemens
Siemens SIMATIC S7 automation module 6ES7505-0KA00-0AB0
Siemens
Siemens SIRIUS 3SK1 safety relay 3SK1111-1AW20
Siemens
Siemens SIMATIC S7 automation module 6ES7431-1KF20-0AB0
Siemens
Siemens SITOP DC power supply 6EP1333-4BA00
Technical guides
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 5SM2342-6KK01?
- 5SM2342-6KK01 can be ordered from cballast.com as a Siemens catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Siemens product?
- The manufacturer part number is 5SM2342-6KK01.
- What is the HS code for 5SM2342-6KK01?
- The customs tariff (HS) code for 5SM2342-6KK01 is 8536.90.
- Who manufactures 5SM2342-6KK01?
- 5SM2342-6KK01 is a Siemens product in the Electrical Components range.
- Is a datasheet available for 5SM2342-6KK01?
- Yes — the 5SM2342-6KK01 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 5SM2342-6KK01?
- The minimum order quantity is 1.
- Is 5SM2342-6KK01 available?
- Yes — 5SM2342-6KK01 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
