Schneider Electric Modular 1-Phase voltage control relay, 8 A, 2 CO, 0.05…5 V AC/DC, 24…240 V AC/DC RM22UA31MR

Schneider Electric RM22UA31MR Zelio Kontrollrele, Voltage.

Manufacturer part number (MPN)

RM22UA31MR EAN / GTIN: 3606480792236 Sales unit: pcs Package quantity: 40 pcs Range of product: Harmony Control Relays Relay type: Voltage control relay Product or component type: Voltage control relay Relay name: RM22UA Network number of phases: 1 phase Relay monitored parameters: Undervoltage and overvoltage in window mode; Overvoltage or undervoltage detection Supply circuit type: DC Control type: With test button Contacts type and composition: 2 C/O [Us] rated supply voltage: 24...240 V AC/DC 50/60 Hz, non self-powered Supply voltage limits: 20.4…264 V AC/DC Measurement range: 0.05...5 V AC/DC Hysteresis: 3 % fixed of full scale for window mode; 5…50 % adjustable of threshold setting Repeat accuracy: +/- 0.5 % for input and measurement circuit; +/- 2 % for time delay Measurement error: < 1 % over the whole range with voltage variation; 0.05 %/°C with temperature variation Time delay type: Adjustable 0.1...30 s, +/- 10 % of the full scale value Tt- time delay upon fault Setting accuracy of time delay: 10 % Reset time: 1500 ms at maximum voltage Response time: <= 500 ms Power on delay: 600 ms Output contacts: 2 C/O nominal output current: 8 A Maximum switching voltage: 250 V AC Switching capacity in VA: 2000 VA minimum switching current: 10 mA at 5 V DC Maximum switching current: 8 A AC Electrical durability: 100000 cycles Mechanical durability: 10000000 cycles Contacts material: Cadmium free Power consumption in VA: 3.5 VA AC Maximum power consumption in W: 1.5 W DC Resistance across terminals: 30 kOhm at E2-M terminals; 5 kOhm at E1-M terminals; 50 kOhm at E3-M terminals Maximum measuring cycle: 100 ms measurement cycle as true rms value Insulation: Between supply and measurement Electromagnetic compatibility: Immunity for residential, commercial and light-industrial environments conforming to IEC 61000-6-1; Immunity for industrial environments conforming to IEC 61000-6-2; Emission standard for residential, commercial and light-industrial environments conforming to IEC 61000-6-3; Emission standard for industrial environments conforming to IEC 61000-6-4; Electrostatic discharge - test level: 6 kV level 3 (contact discharge) conforming to IEC 61000-4-2; Electrostatic discharge - test level: 8 kV level 3 (air discharge) conforming to IEC 61000-4-2; Radiated radio-frequency electromagnetic field immunity test - test level: 10 V/m level 3 conforming to IEC 61000-4-3; Electrical fast transient/burst immunity test - test level: 4 kV level 4 (direct) conforming to IEC 61000-4-4; Electrical fast transient/burst immunity test - test level: 2 kV level 4 (capacitive coupling) conforming to IEC 61000-4-4; Conducted and radiated emissions class B group 1 conforming to CISPR 11; Conducted and radiated emissions class B conforming to CISPR 22 Standards: IEC 60255-1 Product certifications: CE; CSA; RCM; GL; CCC; EAC; UL Ambient air temperature for storage: -40…70 °C; -40…70 °C Ambient air temperature for operation: -20…50 °C at 60 Hz; -20…60 °C at 50 Hz Relative humidity: 93…97 % at 25…55 °C conforming to IEC 60068-2-30 Vibration resistance: 0.075 mm (f= 10…58.1 Hz) not in operation conforming to IEC 60068-2-6; 1 gn (f= 10…58.1 Hz) not in operation conforming to IEC 60068-2-6; 0.035 mm (f= 58.1…150 Hz) in operation conforming to IEC 60068-2-6; 0.5 gn (f= 58.1…150 Hz) in operation conforming to IEC 60068-2-6 Shock resistance: 15 gn (duration = 11 ms) for not in operation conforming to IEC 60068-2-27; 5 gn (duration = 11 ms) for in operation conforming to IEC 60068-2-27 IP degree of protection: IP20 (terminals) conforming to IEC 60529; IP40 (housing) conforming to IEC 60529; IP50 (front panel) conforming to IEC 60529 Pollution degree: 3 conforming to IEC 60664-1 Overvoltage category: III conforming to IEC 60664-1 Dielectric test voltage: 2.5 kV, 1 min AC 50 Hz conforming to IEC 60255-27 Insulation resistance: > 100 MOhm at 500 V DC Connections - terminals: Screw terminals, 2 x 0.5...2 x 2.5 mm² (20 AWG...14 AWG) solid without cable end; Screw terminals, 2 x 0.2...2 x 1.5 mm² (24 AWG...16 AWG) flexible with cable end; Screw terminals, 1 x 0.5...1 x 3.3 mm² (20 AWG...12 AWG) solid without cable end; Screw terminals, 1 x 0.2...1 x 2.5 mm² (24 AWG...14 AWG) flexible with cable end Tightening torque: 0.6…1 N.m conforming to IEC 60947-1 Housing material: Polycarbonate Mounting support: 35 mm DIN rail conforming to IEC 60715 Reliability data: MTTFd = 308.2 years; B10d = 290000 Width: 22.5 mm; 22.9 mm Height: 90 mm; 88.9 mm Depth: 72 mm; 73.7 mm Product weight: 0.11 kg; 0.11 kg Unit Type of Package 1: PCE Number of Units in Package 1: 1 Package 1 Height: 2.600 cm Package 1 Width: 8.200 cm Package 1 Length: 9.500 cm Package 1 Weight: 121.000 g Unit Type of Package 2: S02 Number of Units in Package 2: 40 Package 2 Height: 15.000 cm Package 2 Width: 30.000 cm Package 2 Length: 40.000 cm Package 2 Weight: 5.292 kg Country of origin: ID Warranty (in months): 18 Type of electric connection: Screw connection With detachable clamps: No Single-phase under voltage possible: Yes Three-phase under voltage possible: No Single-phase overvoltage possible: Yes Three-phase overvoltage possible: No Single-phase hysteresis possible: Yes Three-phase hysteresis possible: No Contains function DC-under voltage: Yes Contains function DC overvoltage: Yes Contains function DC-voltage hysteresis: Yes Voltage measuring range 1: 0.05–5 V Voltage measuring range 2: 0.05–5 V Type of voltage measuring range: AC/DC Rated control supply voltage AC 50 Hz: 24–240 V Rated control supply voltage AC 60 Hz: 24–240 V Rated control supply voltage DC: 24–240 V Voltage type for actuating: AC/DC Response value voltage: 20.4–264 V Min. adjustable delay-on energization time: 0 s Max. permitted delay-on energization time: 0.6 s Min. adjustable off-delay time: 0.1 s Max. permitted off-delay time: 30 s Number of contacts as change-over contact: 2

HS Code

8536.49

• EAN 3606480792236
• SAP 1000713431
• Code 8237110
