Schneider Electric set of 2 PanelSeT SF/SM partial 19" swing rack supports - 600 mm NSYRSWSP6

Schneider Electric NSYRSWSP6 Set a 2 Spacial SF/SM - 19" - Split swing frame brackets - 600 mm.

Manufacturer part number (MPN)

NSYRSWSP6

EAN / GTIN

3606480067396

Sales unit

pcs

Range

PanelSeT

Accessory / separate part category

Enclosure accessory

Product or component type

Swing rack support

Application

Electronic application; Multi-purpose

For enclosure nominal dimensions

-

Mounting support

Cross rails, for height or depth adjustment; 19" multiple bracket

Range compatibility

PanelSeT PanelSeT SF; PanelSeT PanelSeT SM; PanelSeT PanelSeT SF-E

Device composition

fixing elements; 2 support

Quantity per set

Set of 1

Material

Steel

Surface finish

Zinc coated

Fixing mode

By fixing element: structure of enclosure

Adjustment

Adjustable in height or depth with a pitch of 25 mm

Height

45 mm

Width

Nominal: 600 mm; 650 mm

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

4.000 cm

Package 1 Width

7.000 cm

Package 1 Length

65.000 cm

Package 1 Weight

1.818 kg

Unit Type of Package 2

PAL

Number of Units in Package 2

20

Package 2 Height

29.000 cm

Package 2 Width

37.500 cm

Package 2 Length

120.000 cm

Package 2 Weight

36.360 kg

Country of origin

ES

Warranty (in months)

18

Model

Swing frame mounting

Suitable for enclosure building width

600 mm

Depth

650 mm

HS Code

8538.10

• EAN 3606480067396
• SAP 1000470680
• Code 8932252
