Schneider Electric Front Vertical Connection Cover NS-MTZ1/NT PrismaSet P LVS04852
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric LVS04852 Frontilkoblingsdeksel for vertical mounted NS/MTZ1 withdrawable in PrismaSeT P.
Technical Specifications
- Manufacturer part number (MPN)
- LVS04852
- EAN / GTIN
- 3606481880178
- Sales unit
- pcs
- Range
- PrismaSeT
- Range of product
- PrismaSeT P
- Product or component type
- Front connection cover
- Accessory / separate part category
- Interface accessory
- Range compatibility
- PrismaSeT PrismaSeT P framework
- Cubicle partitioning form
- Form 1
- installation description
- Cubicle - width 650 mm, depth 400 mm
- Installed device
- Vertical drawout NS630b...1600; Vertical fixed + drawout NT06...16
- Number of vertical modules [50 mm]
- 4
- Quantity per set
- Set of 1
- Width
- 573 mm
- Surface finish
- Matt; Textured
- Protective treatment
- Electrophoresis treatment and hot-polymerised polyester epoxy powder
- Colour
- White (RAL 9003)
- Product weight
- 7.34 kg
- Unit Type of Package 1
- PCE
- Number of Units in Package 1
- 1
- Package 1 Height
- 4.000 cm
- Package 1 Width
- 68.500 cm
- Package 1 Length
- 105.500 cm
- Package 1 Weight
- 7.100 kg
- Unit Type of Package 2
- P12
- Number of Units in Package 2
- 12
- Package 2 Height
- 62.500 cm
- Package 2 Width
- 80.000 cm
- Package 2 Length
- 120.000 cm
- Package 2 Weight
- 105.000 kg
- Country of origin
- FR
- Warranty (in months)
- 18
- Suitable for enclosure building width
- 650 mm
- Suitable for enclosure building depth
- 400 mm
- Surface finishing
- Powder coating
- RAL-number
- 9003
- With cable entry
- No
- With lock
- No
- Construction type
- Individual part
- For internal separation form 2a
- No
- For internal separation form 2b
- No
- For internal separation form 3a
- No
- For internal separation form 3b
- No
- For internal separation form 4a
- No
- For internal separation form 4b
- No
Standards & Compliance
- HS Code
- 7326.90
Cross References
- EAN 3606481880178
- SAP 1200547166
- Code 82880425
Product Documentation
