NG125N/C 100-3 Modular Power Switch
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric 18642 NG125N/C 100-3 Modular power switch
Technical Specifications
- Manufacturer part number (MPN)
- 18642
- EAN / GTIN
- 3303430186427
- Sales unit
- pcs
- Package quantity
- 18 pcs
- Power loss
- 5.2 W
- Built-in depth
- 47 mm
- Release characteristic
- C
- Number of poles (total)
- 3
- Number of protected poles
- 3
- Rated current
- 100 A
- Rated voltage
- 400 V
- Rated insulation voltage Ui
- 690 V
- Rated impulse withstand voltage Uimp
- 8 kV
- Frequency
- 50–60 Hz
- Concurrently switching neutral conductor
- No
- Overvoltage category
- 4
- Pollution degree
- 3
- Additional equipment possible
- Yes
- Width in number of modular spacings
- 4.5
- Degree of protection (IP)
- IP20
- Ambient temperature during operating
- -30–70 °C
- Connectable conductor cross section multi-wired
- 10–50 mm²
- Connectable conductor cross section solid-core
- 16–70 mm²
- Explosion-proof
- No
- Flush-mounted installation
- No
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.20
Cross References
- EAN 3303430186427
- SAP 1000025585
- Code 8196578
Product Documentation
More from Schneider Electric
Schneider Electric
Schneider Electric MX shunt release, ComPacT NSX, rated voltage 525 VAC 50 Hz, 600 VAC 60 Hz, screwless spring terminal connections LV429389
Schneider Electric
Center feed 63A (KNA63ABT4)
Schneider Electric
Schneider Electric Horizontal transport length, Canalis KSA800, aluminium, 800A, fixed length 5M, 3L+N+PE, white RAL9001 KSA800ET450
Schneider Electric
Schneider Electric Harmony XAP, XB2 SL, Empty control station, zinc alloy, orange, M25, 4 cut-outs 30mm with notches, 80 x 220 x 77 XAPO4604
Schneider Electric
Schneider Electric Push button, Harmony XB7, round black flush, 22mm, push to release, 1NO, unmarked XB7NH21
Schneider Electric
Potensiometerknapp 0-10(300gr) (ZB4BD922)
Schneider Electric
Passiva filter 23A 400V 50Hz
VW3A46104
Schneider Electric
Schneider Electric ISFL630 direct 185mm busbar screws M12 - fuse switch-disconnector LV480858
Technical guides
Catalogue entry last verified: 2026-09-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 18642?
- 18642 can be ordered from cballast.com as a Schneider Electric catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Schneider Electric product?
- The manufacturer part number is 18642.
- What is the HS code for 18642?
- The customs tariff (HS) code for 18642 is 8536.20.
- Who manufactures 18642?
- 18642 is a Schneider Electric product in the Electrical Components range.
- Is a datasheet available for 18642?
- Yes — the 18642 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 18642?
- The minimum order quantity is 1.
- Is 18642 available?
- Yes — 18642 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
