Schneider Electric Mureva Fire-Rated Junction Box 80x80x45 mm Red
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric ENN05164 is a Mureva fire-rated junction box for security circuits, sized 80 x 80 x 45 mm with a red snap-on cover and seven 20 mm grommeted cable entries. The PP body carries an IP55 rating (IEC 60529), IK07 impact rating (EN 50102), Class II electrical insulation (IEC 536) and a 960 °C glow-wire temperature. Wall or ceiling surface mounting is supported, with operating temperature -25 to 40 °C and a maximum conductor cross-section of 20 mm². The red RAL 3000 cover identifies safety-circuit wiring for fire-alarm and life-safety installations.
Technical Specifications
- Manufacturer part number (MPN)
- ENN05164
- EAN / GTIN
- 3295150051645
- Sales unit
- pcs
- Package quantity
- 5 pcs
- Dimensions
- 80×80×45
- product range
- Mureva BOX
- product type
- Junction box for security circuits
- quantity per package
- 5 pieces
- Main colour tint
- Red
- Mounting
- Surface
- cable entry
- Grommets
- Fixing mode
- Clip-on: cover
- Inner dimensions
- 80 x 80 x 45 mm
- number of cable entries
- 7 diameter: 20 mm
- Material
- PP (polypropylene): body and cover; SBS (styrene butadiene styrene): grommet
- Electrical insulation class
- Class II conforming to IEC 536
- Height
- 51 mm
- Width
- 98 mm
- Depth
- 98 mm
- Product weight
- 0.073 kg
- Colour tint
- Red (RAL 3000)
- operating temperature
- -25…40 °C
- IP-Class
- IP55 conforming to IEC 60529
- IK-Class
- IK07 conforming to EN 50102
- glow wire temperature
- 960 °C
- Standards
- EN 60670; CE
- Environmental characteristic
- Slightly halogenated
- Number of Units in Package 1
- 1
- Number of Units in Package 2
- 5
- Number of Units in Package 3
- 100
- Warranty (in months)
- 18
- Model
- Junction box
- RAL-number (similar)
- 3000
- Max. conductor cross section
- 20 mm²
- Equipped with
- None
- Shape
- Square
- Mounting method
- Wall-/ceiling mounting
- Mounting in the soil
- No
- Mounting under water
- No
- For tube diameter
- 20 mm
- Inlet from the rear
- No
- Length
- 51 mm
- Connectable
- No
- Number of inlets
- 7
- Type of housing feed-through
- Seal membrane
- Halogen free
- Yes
- Surface protection
- Untreated
- Colour
- Red
- Degree of protection (IP)
- IP55
- Cover model
- Blind cover
- Transparent cover
- No
- Cover attachment
- Snapped on
- Castable
- No
- Casting compound included
- No
- Sealable
- No
- Circuit integrity
- None
- With screening
- No
- Weatherproof
- Yes
- Explosion-tested version
- No
- For Ex-zone gas
- None
- For Ex-zone dust
- None
- Country of origin
- Poland
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 3295150051645
- SAP 1200058162
- Code 81900131
Product Documentation
