Rittal 6315250 AX Operating Enclosure 380x300x210 mm with Handle Strips
Pricing
Request a quote
We reply within 24 hours
Product Description
Rittal AX 6315.250 operating enclosure with aluminium handle strips, 380 x 300 x 210 mm (W x H x D), carbon steel body with all-round foamed PU seal, front serviceable. RAL 7035 housing, natural anodised aluminium front panel and handle strips. Supplied with interior mounting bracket and 3 mm double-bit cam lock.
Technical Specifications
- Manufacturer part number (MPN)
- 6315250
- EAN / GTIN
- 4028177923140
- Sales unit
- pcs
- Model designation
- AX 6315.250
- Product type
- Operating housing AX with handle
- Version
- Support arm connection Ø 130 mm
- Material
- Housing: Carbon steel; Door: Carbon steel, all-round foamed-in PU seal; Front panel: Aluminum; Cover caps: Plastic
- Surface finish
- Housing and door: Dipcoat primed, powder-coated on the outside, textured paint; Handle strip: Natural anodized; Front panel: Natural anodized.
- General color
- RAL 7035
- Color
- Housing and door: RAL 7035; Handle strip: Natural anodized; Front panel: Natural anodized.; Cover caps: Similar to RAL 7024
- Supply includes
- Housing with cut-out and reinforcement for support arm connection; Ø 130 mm; Front with maximum cut-out, covered with easily machinable 3 mm aluminum front panel; Side handle strips with cover caps; Integral interior mounting bracket with system punchings; Cam lock with 3 mm double-bit insert
- Dimensions
- Width: 380 mm; Height: 300 mm; Depth: 210 mm
- Protection category NEMA
- NEMA 1; NEMA 12
- Type rating according to UL 50E
- Type 1; Type 12
- IK code
- IK08
- Base material
- Carbon steel
- Note on Model No.
- Compatible mounting plate 5051.370 with shipping bag 5051.300
- Packaging unit
- 1 pc(s).
- Net weight
- 7.7 kg
- Gross weight
- 8.06 kg
- PCF/VE (cradle-to-gate)
- 35.3 kg CO2 eq (Cat B)
- Information regarding the PCF class
- Category B: PCF value (cradle-to-gate) calculated approximately on the basis of the product weight and self-declared
- Customs tariff number
- 94032080
- ETIM 9
- EC002504
- ETIM 8
- EC002504
- ECLASS 8.0
- 27180505
- Approvals
- UL + C-UL (listed)
- Width
- 380 mm
- Height
- 300 mm
- Depth
- 210 mm
- Surface finishing
- Powder coating
- RAL-number
- 7035
- Degree of protection (NEMA)
- 12
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 7326.90
Cross References
- EAN 4028177923140
- SAP 1200380107
- Code 82389204
Product Documentation
