Fluke 87V MAX E2 Industrial Electrician Combo Kit

Get the Fluke 87V MAX Industrial Electrician Combo Kit. Includes Fluke 87V MAX multimeter plus alligator clips, test leads, test probes, and magnetic hanging strap.

Manufacturer part number (MPN)

5160712

Brand

Fluke

Category

Tools

87V MAX

87 V

IP Rating IP 67

IP 30

Battery life 800 hours

400 hours

Drop test 4 meters

3 meters

DC Voltage Range

0.1 mV to 1000 V

DC Voltage Accuracy

±(0.05% + 1)

DC Voltage Maximum Resolution

0.1 mV

AC Voltage/td> Range

0.1 mV to 1000 V

AC Voltage/td> Accuracy

±(0.7% + 4) true-rms

AC Voltage/td> AC Bandwidth

20 kHz with low pass filter; 3 dB @ 1 kHz

AC Voltage/td> Maximum Resolution

0.1 mV

DC Current Range

0.1 μA to 10 A (20 A for 30 seconds maximum)

DC Current Amps accuracy

±(0.2% + 2)

DC Current Maximum resolution

0.01 µA

AC Current Range

0.1 μA to 10 A (20 A for 30 seconds maximum)

AC Current Amps accuracy

±(1.0% + 2) true-rms

AC Current Maximum resolution

0.1 µA

Resistance Range

0.1 Ω to 50 MΩ

Resistance Accuracy

±(0.2% + 1)

Resistance Maximum resolution

0.1Ω

Capacitance Range

0.01 nF to 9999 μF

Capacitance Accuracy

±(1% + 2)

Capacitance Maximum resolution

0.01 nF

Frequency Range

0.5 Hz to 199.99 kHz

Frequency Accuracy

±(0.005% + 1)

Frequency Maximum resolution

0.01 Hz

Duty Cycle Maximum duty cycle

99.9%

Duty Cycle Accuracy

±(0.2% per kHz + 0.1%)

Duty Cycle Maximum Resolution

0.1%

Temperature measurement range

–200.0 °C to 1090 °C –328.0 °F to 1994.0 °F excluding probe

80 BK Temperature Probe

–40.0 °C to 260 °C, ± 2.2 °C or 2% whichever is greater –40.0 °F to 500 °F, ± 4.0 °F or 2% whichever is greater

Conductance Maximum conductance

60.00 nS

Conductance Accuracy

±(1.0% + 10)

Conductance Maximum Resolution

0.01 nS

Diode test Range

2 V

Diode test Resolution

0.001 V

Diode test Accuracy

±(1% + 1)

Diagnostics and data storage Peak Min/Max

250 μS

Min/Max/Avg

Yes

Reading hold/Auto (Touch) Hold

Yes

Relative reference

Yes

Display Digital

6000 counts updates 4/second 19,999 counts in high–resolution mode

Display Analog bar graph

32 segments, updates 40/second

Display Backlight

two level

Low pass filter (VFD measurements)

Yes

Input AlertTM

Yes

Safety rating

IEC61010-1: Pollution Degree 2 IEC 61010-2-033: CAT IV 600 V, CAT III 1000 V

Agency approvals

CE, CSA

Power

Three AA batteries. 800 hours typical, without backlight

Size

6.0 x 10.1 x 21.5 cm (with holster)

Weight

698.5 g (with holster)

Warranty

Limited lifetime

Operating temperature

-15 °C to 55 °C, to -40 °C for 20 minutes when taken from 20 °C

Storage temperature

–40 °C to + 60 °C

Humidity (without condensation)

0% – 90% (0 °C – 35 °C) 0% – 70% (35 °C – 55 °C)

Operating Altitude

2000 m

• OEM-URL https://www.fluke.com/en-us/product/electrical-testing/digital-multimeters/87v-max-e2
