Festo MSFW Solenoid coil - 24V, AC, MSFW-24-50/60-OD
Pricing
Request a quote
We reply within 24 hours
Product Description
Festo MSFW Solenoid coil. Pneumatic coils/cable connectors (Technique / Pneumatics / Pneumatics - Valves). Principal data: voltage 24 V, voltage type AC, supplier type designation MSFW-24-50/60-OD. Supplied under manufacturer part number 34415, EAN 4052568023072, HS code 8505.90, country of origin Germany.
Technical Specifications
- Mounting position
- Any
- Switching position indicator
- No
- Min. pick-up time
- 10 ms
- Duty cycle
- 100%
- Power factor (cos phi)
- 0.7
- Characteristic coil data
- 24 V AC: 50/60 Hz, pick-up power 9.0 VA, holding power 7.0 VA
- Permissible frequency fluctuations
- +/-5%
- Permissible voltage fluctuations
- +/-10%
- LABS (PWIS) conformity
- VDMA24364-C1-L
- Degree of protection
- IP65
- Ambient temperature
- -5 ... 40 °C
- Max. tightening torque for socket
- 0.4 Nm
- Product weight
- 55 g
- Electrical connection
- 3-pin; Plug pins with connection pattern to Festo standard for MSSD-F
- Type of mounting
- Via knurled nut
- Material solenoid coil
- Duroplast; Copper; Steel
- Material winding
- Copper
- EAN / GTIN
- 4052568023072
- Festo type code
- MSFW-24-50/60-OD
- Festo order number
- 34415
- Product type
- Pneumatic coils/cable connectors
- Product group
- Pneumatics
- Voltage
- 24 V
- Voltage type
- AC
- Carbon footprint (EPD)
- 0.3860 kg CO2e per pcs
- Country of origin
- Germany
- Customs tariff code (EU CN)
- 85059029
- HS code
- 8505.90
- Manufacturer part number
- 34415
Standards & Compliance
- HS Code
- 8505.90
Cross References
- EAN 4052568023072
- MPN 34415
