Connection Terminal 16-120mm², f 10M
Pricing
Request a quote
We reply within 24 hours
Overview
Eaton Connection Terminal 16-120mm², f 10M (part number AKU120/10) is listed under Electrical Components / Terminal Blocks. Sales unit: pcs; Package quantity: 25 pcs; Eaton catalogue number: 107194; Depth: 24 mm; Height: 55 mm; Width: 36 mm.
Technical Specifications
- Manufacturer part number (MPN)
- AKU120/10
- EAN / GTIN
- 4015081069576
- Sales unit
- pcs
- Package quantity
- 25 pcs
- Eaton catalogue number
- 107194
- Depth
- 24 mm
- Height
- 55 mm
- Width
- 36 mm
- Weight
- 0.104 kg
- Compliances
- UL CSA09 (refer to approbation report); RoHS conform
- Certifications
- CSA (File No. 236217); UL (Category Control Number NMTR2, NMTR8); IEC 60439-1; UL (File No. E307559); UL508A; CSA (Class No. 3211-37); CSA-C22.2 No. 14; North America (UL listed, CSA certified); CE marking
- Functions
- Current limiting circuit breaker, refer to approbation report; Universal conductor connection terminal; Connections
- Special features
- With integrated retaining spring, open terminal chamber and captive terminal screw
- Suitable for
- Sector conductor connection; Strip conductor connection; Round conductor connection; Flat rail
- Used with
- Feeder circuits; All 10 mm thick flat busbars; Compact system; Connection; 185 mm system; 60 mm system
- Type
- 185 mm system 60 mm system Compact system Connection
- Rated operation current (Ie)
- 440 A
- Rated operational current
- 440 A
- Rated operational current (Ie) - max
- 440 A
- Voltage rating (UL CSA 13)
- Max. 600 V AC
- Busbar thickness - max
- 10 mm
- Busbar thickness - min
- 10 mm
- Conductor cross section - max
- 120 mm²
- Degree of protection
- Feeder circuits; UL508A; CSA-C22.2 No. 14; IEC 60439-1; CE marking
- Terminal capacity (conductor)
- 16 mm x 0.8 mm (6x); AWG 4 - MCM 250; 16 mm x 0.8 mm (10x); 16 mm² - 120 mm²; 16 mm x 0.8 mm (4x)
- Terminal contact area
- 17 mm x 15 mm
- Width clamp
- 23.5 mm
- Max. conductor cross section
- 120 mm²
- Busbar thickness
- 10 mm
- Suitable for strip conductor connection
- Yes
- Suitable for round conductor connection
- Yes
- Suitable for sector conductor connection
- Yes
- Max. rated operation current Ie
- 440 A
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 4015081069576
- SAP 1200607324
- Code 82995640
Product Documentation
More from Eaton
Eaton
Enclosure FOR OV-Protection
IK-PLSM
Eaton
LED flashing light, Orange, 230V (SL7-BL230-A)
Eaton
Safety Switch (DMM-125/4/M4/P-R)
Eaton
Eth, 8TRANS. Q, DISP.
EC4P-222-MTXD1
Eaton
Eaton BeamTech Small 2x500 lm Emergency Luminaire, LiFePO4
BT2SL-F1-AT
Eaton
Busbar 2P+AUX (EVG-16/2PHAS/10MODUL/HI)
Eaton
NexiTech LED 150LM CGLine+
NEXITECH LED 150LM 1H30 CGLine+
Eaton
Styrecontactor 2S+2TO 230V/240V (DILA-22(230V50HZ,240V60HZ))
Technical guides
Catalogue entry last verified: 2026-09-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy AKU120/10?
- AKU120/10 can be ordered from cballast.com as a Eaton catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Eaton product?
- The manufacturer part number is AKU120/10.
- What is the HS code for AKU120/10?
- The customs tariff (HS) code for AKU120/10 is 8536.90.
- Who manufactures AKU120/10?
- AKU120/10 is a Eaton product in the Electrical Components range.
- Is a datasheet available for AKU120/10?
- Yes — the AKU120/10 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for AKU120/10?
- The minimum order quantity is 1.
- Is AKU120/10 available?
- Yes — AKU120/10 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
