Eaton BeamTech Small 2x500 lm Emergency Luminaire, LiFePO4
Pricing
Request a quote
We reply within 24 hours
Product Description
The Eaton BT2SL-F1-AT is a compact emergency escape-route luminaire with two adjustable heads delivering 1000 lm at 4000 K. It is rated IP65 and IK07 for wall or ceiling surface mounting and uses a non-exchangeable LED source powered by an individual LiFePO4 battery with a 10-year design life. Automatic self-test and a 1-hour rated operating duration support code-compliant escape lighting in industrial, commercial and public buildings.
Technical Specifications
- Manufacturer part number (MPN)
- BT2SL-F1-AT
- EAN / GTIN
- 5205050910896
- HS code
- 8543.70
- Sales unit
- pcs
- Package quantity
- 6 pcs
- Suitable for continuous circuit
- No
- Suitable for standby switching
- No
- Mounting method
- Wall surface mounting/ceiling surface mounting
- Function
- Escape route lighting
- With pictogram
- No
- Monitoring equipment
- Automatic self test
- Wiring system
- Standby switching
- With remote switch connection
- No
- With remote control
- No
- Power supply system
- Peripheral (individual battery)
- Battery technology
- Lithium-ion
- Lamp type
- LED not exchangeable
- With light source
- Yes
- Suitable for number of light sources
- 24
- Lamp holder
- None
- Number of lighting heads
- 2
- Housing material
- Plastic
- Housing colour
- White
- Material cover
- Plastic, structured
- Voltage type
- AC
- Nominal voltage
- 207–253 V
- Type of control gear
- Not required
- Exchangeable control gear
- No
- Light distributor
- Focal lens
- Luminous flux in emergency mode
- 1000 lm
- Constant light output (CLO)
- No
- Degree of protection (IP)
- IP65
- Impact strength
- IK07
- Protection class according to IEC 61140
- II
- Rated ambient temperature according to IEC 62722-2-1
- 5–40 °C
- Max. system power
- 4 W
- Rated luminous flux according to IEC 62722-2-1
- 1000 lm
- Colour temperature
- 4000 K
- Power factor
- 0.9
- Nominal operation time
- 1 h
- Width
- 155 mm
- Height/depth
- 69 mm
- Length
- 466 mm
- Type of wiring
- Suitable for loop-through wiring
- Number of poles
- 3
- Conductor cross section
- 2.5 mm²
- Connection type
- Screw connection
- RAL-number housing
- 9003
- Connectable conductor cross section
- 0.5–1.5 mm²
- Emergency power supply system
- Peripheral (individual battery)
- Power consumption in emergency mode
- 4.5 W
- Emergency function monitoring system
- None
- With heating element for battery
- No
- Type of lithium-ion battery
- Lithium iron phosphate (LiFePO4)
- Country of origin
- Romania
Standards & Compliance
- HS Code
- 8543.70
Cross References
- EAN 5205050910896
- SAP 1200611427
- Code 83013849
