Residual current circuit breaker 80A 4P 300MA S/A
Pricing
Request a quote
We reply within 24 hours
Product Description
Eaton PFIM-80/4/03-S/A Residual current circuit breaker, 80A, Selective A-Type.
Technical Specifications
- Manufacturer part number (MPN)
- PFIM-80/4/03-S/A
- EAN / GTIN
- 4015082354756
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 3 pcs
- Rated current
- 80 A
- Number of poles
- 4
- Mounting method
- DIN rail
- Colour
- Grey
- Voltage type
- AC
- Built-in depth
- 70.5 mm
- Rated voltage
- 400 V
- Rated insulation voltage Ui
- 440 V
- Rated fault current
- 0.3 A
- Leakage current type
- A
- Selective protection
- Yes
- Short-circuit breaking capacity (Icw)
- 10 kA
- Surge current capacity
- 5 kA
- Pollution degree
- 2
- Width in number of modular spacings
- 4
- Short-time delayed tripping
- No
- RAL-number (similar)
- 7035
- Explosion-proof
- No
- Power loss
- 11.4 W
- Frequency
- 50 Hz
- Degree of protection (IP)
- IP20
- Connectable conductor cross section solid-core
- 1.5–35 mm²
- Connectable conductor cross section multi-wired
- 1.5–16 mm²
- With interlocking device
- Yes
- Ambient temperature during operating
- -25–40 °C
- Additional equipment possible
- Yes
- Device width
- 70 mm
- Device height
- 80 mm
- Device depth
- 76 mm
- Rated impulse withstand voltage Uimp
- 4 kV
- Country of origin
- Romania
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 4015082354756
- SAP 1000059571
- Code 8865088
Product Documentation
More from Eaton
Eaton
Eaton FAZ-B32/2 Miniature Circuit Breaker — 2P, Type B, 32 A, 15 kA
Eaton
Complete Emergency Stop, Push/Pull, 1 NC
M22-PV/K01
Eaton
Eaton NZM2-4-250-XKC
Eaton
Bell Transformer MOD 230/12-24V50HZ
TR-G2/63-SF
Eaton
Eaton M22 Rotary Switch with Grip 1-0-2 Momentary
M22-WK3
Eaton
Eaton xPole PFIM Residual Current Circuit Breaker (RCCB) — Type A, 4-Pole, 40 A, 300 mA, Instantaneous
PFIM-40/4/03-A-MW
Eaton
Eaton EP-502627 xComfort Bridge Energy Control for Smart Meter
Eaton
Eaton NZMH3-4-VX400/VAR Molded-Case Circuit Breaker 4-Pole 400A 150KA
Catalogue entry last verified: 2026-09-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy PFIM-80/4/03-S/A?
- PFIM-80/4/03-S/A can be ordered from cballast.com as a Eaton catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Eaton product?
- The manufacturer part number is PFIM-80/4/03-S/A.
- What is the HS code for PFIM-80/4/03-S/A?
- The customs tariff (HS) code for PFIM-80/4/03-S/A is 8536.90.
- Who manufactures PFIM-80/4/03-S/A?
- PFIM-80/4/03-S/A is a Eaton product in the Electrical Components range.
- Is a datasheet available for PFIM-80/4/03-S/A?
- Yes — the PFIM-80/4/03-S/A datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for PFIM-80/4/03-S/A?
- The minimum order quantity is 1.
- Is PFIM-80/4/03-S/A available?
- Yes — PFIM-80/4/03-S/A is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
