Eaton T0-1-8220/XZ Single-Pole 2-Step Cam Switch 20 A

Eaton T0-1-8220/XZ combination single-pole reversing switch without 0 position, 2 steps, rated 20 A at AC-1 and 4 kW at AC-3 400 V. Short thumb-grip actuator; plastic enclosure; IP65 front and rear mounting; screw main-circuit connection.

Manufacturer part number (MPN)

T0-1-8220/XZ

EAN / GTIN

4015080095637

Sales unit

pcs

Eaton catalogue number

009563

Depth

48 mm

Height

48 mm

Width

48 mm

Weight

0.07 kg

Certifications

CE

Actuator type

Short thumb-grip

Number of auxiliary contacts (change-over contacts)

0

Number of auxiliary contacts (normally closed contacts)

0

Number of auxiliary contacts (normally open contacts)

0

Number of contacts

2

Rated operational current (Ie) at AC-21, 440 V

20 A

Rated operational current (Ie) at AC-3, 380 V, 400 V, 415 V

11.5 A

Rated operational power at AC-3, 380/400 V, 50 Hz

4 kW

Rated uninterrupted current (Iu)

20 A

Enclosure material

Plastic

Number of poles

Single-pole

Degree of protection

IP65; NEMA 12

Degree of protection (front side)

IP65; NEMA 12

Model

Reverser

Mounting method

Rear mounting

Mounting position

As required

Number of contact units

1

Overvoltage category

III

Pollution degree

3

Suitable for

Ground mounting; Intermediate mounting; Front mounting

Switching angle

90 °

Rated operation power at AC-3, 400 V

4 kW

Rated permanent current Iu

20 A

Rated operation current Ie at AC-3, 400 V

11.5 A

With zero (off) position

No

Housing material

Plastic

With retraction in 0-position

No

Degree of protection (IP), front side

IP65

Type of electrical connection of main circuit

Screw connection

Suitable for floor mounting

Yes

Suitable for front mounting

Yes

Suitable for distribution board installation

No

Suitable for intermediate mounting

Yes

Complete device in housing

No

Country of origin

United Kingdom

HS Code

8536.50
