Danfoss VLT AutomationDrive FC-302 11kW
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss VLT FC-302 advanced automation drive. 11kW with high dynamic performance for demanding applications. IP55 enclosure for harsh marine environments.
Technical Specifications
- Type
- Advanced Automation Drive
- Part Number
- 131B1178
- Rated Power
- 11 kW / 15 HP
- Input
- 380-500V 3-phase
- IP Rating
- IP55
- Control
- Open/closed loop vector
- Fieldbus
- Profibus, DeviceNet, CANopen options
- Safety
- Safe Stop SS1
- Product Group
- FC-
- Series
- 302
- Power Rating
- P11K
- Phase
- T
- Mains Voltage
- 5
- Enclosure
- E55
- RFI Filter
- H2
- Brake - Safe Stop
- B
- LCP
- G
- Coating PCB
- X
- Mains Option
- X
- Adaptation A
- X
- Adaptation B
- X
- Software Release
- SXXX
- Software Language Pack
- X
- A Option
- AX
- B Option
- BX
- C0 Option MCO
- CX
- C1 Option
- X
- C Option Software
- XX
- D Option
- DX
- Frame Size
- B1
- Product Catalog
- NO_VIEW
- Power 160% (HO) [KW]
- 11
- Power 110% (NO) [KW]
- 15
- Power Loss HO [W]
- 291
- Power Loss NO [W]
- 392
- kVA
- 16.6
- Continuous Current (HO) [A]
- 24
- Intermittent Current (HO) [A]
- 38.4
- Continuous Current (NO) [A]
- 27
- Intermittent Current (NO) [A]
- 35.2
- Height [mm]
- 494,0
- Width w/ no C options [mm]
- 243,0
- Depth [mm]
- 261,0
- Depth with Option A/B [mm]
- 261,0
- ECCN EU
- Y901
- ECCN US
- 3A999.a
- Product View (Switch)
- GLBL
Standards & Compliance
- Classification / Approval
- CE, UL, cUL, CSA, RCM, EAC, DNV, ABS, LR, BV, ClassNK, KR, RINA
- HS Code
- 8504.40
Compatibility & Fitment
Standard input/output. Check kW rating and voltage to match your application.
