Danfoss SVL 125 multifunction valve body, straightway, 125 mm (5 in) butt weld EN 10220, steel, 52 bar (code 148B6113)
Danfoss · HVAC & Refrigeration · Globe Valves
Danfoss SVL 125 multifunction valve body (bare housing) for the SVL Flexline programme, code 148B6113. Steel housing with butt weld connections to EN 10220, nominal size 125 mm (5 in), straightway pattern. The SVL body is the welded-in-line valve housing onto which an SVL Flexline function module (SVA-S/SVA-L shut-off, REG regulating, SCA-X/CHV-X stop-check or check) of matching size is mounted to make up a complete valve. Maximum working pressure 52 bar (754 psig); media temperature range -60 to 150 C (-76 to 302 F). Housing and function module are ordered separately. For R717 (ammonia), R744 (CO2) and fluorinated refrigerants and their oils.
Specifications
- Part number
- 148B6113
- HS code
- 8481.90
- Material
- Steel
- Pressure rating
- 52 bar
- Temperature range
- -60 to 150 C
- Standard
- EN 10220
- Standard size
- 125 mm
Compatibility
Danfoss SVL Flexline 125 mm valve body (housing only). Weld this housing into the line, then fit the required function module (SVA-S/SVA-L shut-off, REG regulating, SCA-X/CHV-X stop-check/check) of the same 125 mm size to build a complete valve. Confirm direction (straightway) and connection standard (EN 10220); EN 10220 and ASME weld ends are separate codes and not interchangeable.
Approvals
