Danfoss SVA-S 25 straightway shut-off valve, 25 mm (1 in) ANSI/ASME B1.20.1 NPT, steel, 52 bar, cap (code 148B5435)
Danfoss · HVAC & Refrigeration · Globe Valves
Danfoss SVA-S 25 shut-off (stop) valve from the SVL Flexline industrial-refrigeration range, store code 148B5435, straightway body. Used to isolate a line section for service or component exchange. Supplied with a seal cap in place of the handwheel for set-and-secure duty. Nominal size 25 mm (1 in) with NPT connections to ANSI/ASME B1.20.1. Steel body for R717 (ammonia), R744 (CO2) and fluorinated refrigerants and their oils. Maximum working pressure 52 bar (754 psig); media temperature range -60 to 150 C (-76 to 302 F). Flow coefficient Kv 22.4 m3/h (Cv 25.98 gal/min). The SVA-S back-seating spindle allows the gland to be repacked under pressure. Specifications per Danfoss store code 148B5435.
Specifications
- Part number
- 148B5435
- HS code
- 8481.80
- Material
- Steel
- Pressure rating
- 52 bar
- Temperature range
- -60 to 150 C
- Standard
- ANSI/ASME B1.20.1
- Standard size
- 25 mm
- Thread standard
- ANSI/ASME B1.20.1
Compatibility
Danfoss SVL Flexline SVA-S 25. Shares the SVL Flexline platform with SVA-S/SVA-L shut-off, REG regulating, SCA-X/CHV-X check and FIA strainer components of the same nominal size. EN 10220 and ASME weld-end preparations are not interchangeable — confirm the mating pipe schedule before ordering.
Standards
- ANSI/ASME B1.20.1
- PED 2014/68/EU Art. 4 par. 3
